EY28 series four-column double-action hydraulic press
US$ 1 - 10,000
/ Set
1 Set(Min. Order)
- Shanghai Port
You May Like
Product Details
| Condition | New | CNC or Not | Normal | |
| Power Source | Hydraulic | Place of Origin | Jiangsu, China | |
| Brand Name | Gaintally |
Product Description
Specifications
1. good performance2. excellent hydraulic system
3.easy operation and repair
The series is double-action hydraulic press, especially used for sheet metal process such as drawing, flanging and bending, etc. It can also be available for general purposes.
Its operation is easy with two-cartridge valve in hydraulic system and PLC control in electric system.
With advantages of high idle speed and adjustable blank-holding force, it would be your ideal equipment to process sheet metal.
| No. | Item | Type Unit | EJY28-400/630 | EJY28-500/800 | EJY28-630/1030 | |
| 1 | Main pressure force | kN | 6300 | 8000 | 10300 | |
| 2 | Drawing ram force | kN | 4000 | 5000 | 6300 | |
| 3 | Press ram blank force | kN | 2300 | 3000 | 4000 | |
| 4 | Hydraulic cushion force | kN | 1500 | 2000 | 2400 | |
| 5 | Drawing ram return force | kN | 500 | 700 | 700 | |
| 6 | Press ram return force | kN | 500 | 700 | 700 | |
| 7 | Hydraulic cushion ejecting stroke | kN | 500 | 630 | 800 | |
| 8 | Liquid max pressure | Mpa | 25 | 25 | 25 | |
| 9 | Drawing max distance between ram to table | mm | 1700 | 2000 | 2200 | |
| 10 | Max distance between blank ram to table | mm | 1700 | 2000 | 2200 | |
| 11 | Drawing ram max stroke | mm | 1000 | 1100 | 1300 | |
| 12 | Pressing ram max stroke | mm | 1000 | 1100 | 1300 | |
| 13 | Hydraulic cushion stroke | mm | 300 | 350 | 400 | |
| 14 | Pressing ram size | mm | 2500×1800 | 3000×2000 | 3200×2200 | |
| 15 | Hydraulic cushion size | mm | 1800×1200 | 2300×1400 | 2500×1500 | |
| 16 | cam block drawing size | right and left | mm | 1800 | 2300 | 2500 |
| front and rear | mm | 1200 | 1400 | 1500 | ||
| 17 | Worktable size | right and left | mm | 2500 | 3000 | 3200 |
| front and rear | mm | 1800 | 2000 | 2200 | ||
| 18 | cam block drawing speed | fast down speed | mm/s | 300 | 300 | 300 |
| drawing speed | mm/s | 10-45 | 10-45 | 10-45 | ||
| return stroke | mm/s | 200 | 200 | 200 | ||
| 19 | Camblock speed | fast down speed | mm/s | 300 | 300 | 300 |
| working | mm/s | 10-45 | 10-45 | 10-45 | ||
| return stroke | mm/s | 200 | 200 | 200 | ||
| 20 | power | kW | 120 | 160 | 180 | |
| 21 | weight | t | 130 | 160 | ||
