Home > Products > Shrink wrapping machine > High Speed Fully Automatic Shrink Wrapping Machine
High Speed Fully Automatic Shrink Wrapping Machine
US$ 2,000 - 10,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T
You May Like
-
Vrey High Speed Shrink Wrapping Machine,four Side Sealing ,TAIWAN Technology
-
Economic Book Shrink Wrapping Machine
-
Good Shrink Wrapping Machine Shrink Packing Machine L Type Cutting and Sealing Machine ,wholesale Manufacture
-
Easy Operate Semi Automatic Carton Strapping Machine With Good Quality
-
Good Quality Se-mi Automatic Carton Strapping Machine With Factory Price
-
Semi-automatic Carton Strapping Machine With Short Delivery Time
Product Details
| Application | Food, Commodity, Medical, Chemical, Other, Apparel, Textiles, Food, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles | Packaging Type | Case | |
| Packaging Material | Wood | Automatic Grade | Automatic | |
| Driven Type | Electric | Voltage | 220V/50HZ | |
| Power | 1.3KW | Place of Origin | Jiangsu, China | |
| Brand Name | Jiajun packing | Model Number | CHL-8040 | |
| Dimension(L*W*H) | 1370x920x1800 | Weight | 600KG | |
| Certification | CE&ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.DUPONT sealing knife ,steady2.Import photoelectric detection, precisely
3.automatic feeding
4.adopt unmanned connections
FULLY CLOSE SEALING(PE) &SHRINKING PACKAGER CHL-8040+SM-8040 |
- FEATURES
- CHL-8040 adopt advanced double side sealer technical, continues sealing. Product length is unlimited
- Adopt electric Touch screen, imported OMRON PLC to integrated mechanism with electricity and pneumatic
- Adopt most advanced side sealing device, wrapper length is unlimited
- Achieve excellent sealing effect
- Especially designed for the big and heavy wrapper
- The sealing line can be set any position of the wrapper. the shrink film thickness 0.03-0.06mm is suitable
- According to customer request, can add front and back conveyor, and color film locating system
- SM-8040 adopt double fan motors make the heat air inside the tunnel evenly
- Different products combination can be sealed perfectly and automatically
- Closed packing for products to realize water proof and light proof
- Adopt PE film to meet long distance transport and won't broken after frequent handling
- Remove the shrinking tunnel. products could be packed by no poison PE shrinking film
DESCRIPTION
- Suitable for floor boards, ceramics, furniture, electric appliances or other shapes of products closed shrinking packing
Model | CHL-8040 | SM-8040 |
Machine dimension L×W×H(mm) | 2300×1600×1600 | 2800×1100×1690 |
Tunnel dimension L×W×H(mm) | / | 1800×800×400 |
Max packing size L×W×H(mm) | L Unlimited×1000×250 | 1500×600×300 |
Sealing size L(mm) | 1000 | / |
Temperature(0C) | 0-200 | 0-400 |
Height of work table (mm) | 850±50 | 850±50 |
Packing speed(Pcs/min) | 6-12 | 40-60 |
Net weight (kg) | 1100 | 700 |
Power (kw) | 3 | 37 |
Power supply | 3PH 220V/380V 50/60Hz | 3PH 220V/380V 50/60Hz |
Air pressure (kg/cm2) | 6-8 | / |
Applicable film | PE | PE |
Details:
Our customers:
Our company:
Looking forward to your feedback
Contact Us
- Suzhou Jiajun Packing Machinery Co., Ltd.
- Contact nameJun Wang Chat Now
- Phone0086-512-69171150-802
- AddressNO.26 Chengyang Road, Suzhou City, Jiangsu Province, China, Suzhou, Jiangsu
