Home > Products > Powder Packing Machine > automatic vertical type double rollers high speed small bag seasoning powder packing machine
automatic vertical type double rollers high speed small bag seasoning powder packing machine
- SHANGHAI
- T/T L/C D/P D/A
You May Like
-
automatic multifunction high speed pouch yeast barm packing machine
-
semi-automatic plastic bag washing powder packing machine
-
Plastic,Paper Packaging Material double chamber powder packing machine
-
Auto Pouch Auger Powder Aseptic Filling Packaging Machine
-
semi-automatic Filling packing machine packing powder
-
VFFS automatic back seal sachet coffee powder filling machine
Product Details
| Condition | New | Function | Embossing, Filling, Gluing, Sealing, Slitting | |
| Application | Beverage, Chemical, Commodity, Food, Medical | Packaging Type | Bags, Film, Pouch | |
| Packaging Material | Paper, Plastic | Automatic Grade | Automatic | |
| Driven Type | Electric | Voltage | 380V | |
| Power | 4 KW/AC | Place of Origin | Hubei, China | |
| Brand Name | Hi-Tech | Model Number | HT-K219F-20L | |
| Dimension(L*W*H) | L1400mm*W900mm*H1670mm | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HT-K219F-20L automatic vertical type double rollers high speed small bag seasoning powder packing machine with double roller is designed for implementation of the powder materials automatic packaging. This machine adopts advanced industrial computer control system, through the “man-machine dialogue” can be convenient and accurate implement bag size increase or cut short and the adjustment of the packing speed. The English operation interface can help worker simple and clear to finish most function settings.
The machine has a set of longitudinal sealing hot roller, a set of transverse sealing hot roller. The seals adopt roller method, seal pattern is complete and continuous checkerboard pattern, packing materials injected into packing bags quantitative by feed screw. And equipped with ease open bags cutting device, implementation of bag making, filling, sealing, photoelectric automatic calibration, cutting, counting and other else automatic packing processes.
Characteristic
1, High speed and high precision.
2, man-machine dialogue operation interface.
3, setting of bags length can simple and reliable adjustments in a wide-area.
4, photoelectric automatic calibration within three bags.
5, double variable frequency drive, stable and reliable running.
6, roller suppoted by high temperature bearing, perfect sealing, free maintenance, low noise.
Application scope
Coffee, Sugar, infusion of drugs, desiccant, spices, seeds, pesticides, and other granular material. .
Technical parameters
Bag Size | Length: 50-210mm | Width: 30-200mm |
Packing Speed | 20-120 Bags/min | |
Capacity Range | 1-200g | |
Bag Materials | PET/PE,PET/AV/PE, NY/AL/PE,NY/PE, etc | |
Mechanical Power | 4KW/AC 380V | |
Mechanical Dimensions | L1400mm*W900mm*H1670mm | |
Sealing Method | Three or four edges sealing | |
Net Weight | 400Kg | |
Optional Device | Product conveying belt, Automatic feeding system, Liquid level display device, Mixing system, Third section electric control system, Code machine/Printing machine, Voltage regulator, Air compressor, Back suction device | |
Electrical control system
Longitudinal sealing inverter: | 0.75KW Panasonic inverter |
Transverse sealing incerter: | 1.5KW Panasonic inverter |
Touch screen: | WeinView touch screen |
PLC Module: | Delta PLC |
Temperature Controller: | Omron |
AC contactor: | DELIXI |
Relays: | Omron |
Color logo recognition sensor: | BALEFU |
Angle encoder: | Seiko |
Circuit protector: | DELIXI |
Main Motor: | YUQIU |
Type 80 vertical gear reducer: | YUQIU |
Type 50 horizontal gear reducer: | YUQIU |
Solid state relays: | Tianhao |
Partners
Processing
After Sales Service
·Find our products through or http://hi-techmachinery.en.china.cn
· One year warranty for the whole machine
· Free equipment installation and debugging
·After one year, we can help you to maintain the machine and the accessories are provided omle one the cost price
·Every 3 years, we can help to overhaul the machine freely (labor)
·We can provide internship service and help you train the operator and machunic
·Free production technology and process configuration
