Product Details
| Place of Origin | Jiangsu, China | |||
| Brand Name | gaode | Model Number | HBS-4000 | |
| Voltage | Based on customer | Rated Power | 110 KW | |
| Dimension(L*W*H) | None | Weight | None | |
| Certification | CE;CQC;ISO9001:2008, ISO9001: 2008 | Warranty | 180Days, 6Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HBS Integrated Hydraulic Scrap Metal Baler Shear Machine
Features:
1.Pre-compress and cut scrap
2.Cut bars and profiles
3.Package light scrap
4.Squeeze and cut car bodies
1 | Press Box Size(L*W*H)
| 5000*1600*900mm |
| |||
2 | Bale Size(L*W*H)
| 700*500mm |
| |||
3 | Hydraulic System Pressure | 25 MPa |
| |||
4 | Total Motor | 110KW |
| |||
5 | Power | 380V/3PH,50Hz |
| |||
6 | Blade Length | 800mm |
| |||
7 | Shearing Frequency (times/min) | 3-5 time/min |
| |||
8 | Capacity(Ton/Hour) | 4-12 |
| |||
9 | Max Cutting Force (material Tensile Strength no more than 440MPa) | Round TeelΦ120mm |
| |||
Billet 110*110mm | ||||||
Steel Plate 50*600mm | ||||||
10 | Motor | Model | Y200L2-6 | Nominal Power | 55KW |
|
Nominal Speed | 970rmp | Quantity | 2 pieces |
| ||
11 | Hydraulic Pump | Model | 250YCY14-1B | Nominal Pressure | 31.5MPa |
|
Nominal Outflow | 250ml/r | Quantity | 2 Pieces |
| ||
12 | Equipment Outline Dimension
| 11300*2800*3500(Flank Expansion) | L*W*H | |||
11300*2200*3500mm(Flank Collapsed) | L*W*H | |||||
13 | Floor Space | 14000*4000mm | L*W | |||
14 | Control System | PLC Automatic Control |
| |||
15 | Cooling System | Oil - steam heat exchanger
| ||||
Applications:
The hydraulic baler & shear machinery is suitable for the cutting of scrap materials.Metal pieces are pressed 2-0r-3-dimensionally by using the pressing lid,wing and feeding pusher,and cut or broken into pieces.
