PVC power material mixer machine
- 20 Set / Sets per Month
- Shanghai
- T/T
You May Like
-
pvc powder hot and cooling mixer machine
-
PVC plastic powder mixer machine
-
pvc compound mixer/pvc mixer machine/pvc turbo mixer
-
High speed plastic PVC mixer machine
-
High speed plastic mixer machine /PVC mixing machine / PVC mixer / mixing machine unit
-
High speed plastic mixer machine /PVC mixing machine / PVC mixer
Product Details
| Condition | New | Mixer Type | Homogenizer | |
| Product Type | Other, PVC material power | Application | Other, Powder, PVC mixer machine | |
| Additional Capabilities | Drying | Place of Origin | Jiangsu, China | |
| Brand Name | Sevenstars | Model Number | BDX-SRL | |
| Max. Loading Capacity | 200-1000KG | Voltage | 380V50HZ | |
| Certification | ISO9001 CE, CE ISO9001 | Warranty | 1 YEAR, 1 YEAR | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
PVC power material mixer machine1.Easy to operation
2.Certification: ISO9001:2000 CE
3.hot mix
PVC power material mixer machine
SRL-Z series mixer unit is widely used in mixing, drying, coloring various kinds of resin such as PVC, PP, PE. They can also be used in dryness of ABS and polycarbonate, and mixing hydroxybenzene, aldehyde resin.
The unit consists of one hot mixer and one cooling mixer. The materials from hot mixer get into the cooling mixer automatically to be cooled, so remained gas is eliminated, and agglomeration is avoided.
Absoring advanced foreign technology and PLC control system, we designed SRL-Z series heating/cooling mixer unit, which offers high automatic level, good mixing effetc, complete function, compact structure, and perfect appearance. The unit is widely used in mixing, drying and coloring various plastics.
| Main Technical Parameters | |||||
| Parameter/Model | SRL-Z50/100A | SRL-Z100/200A | SRL-Z200/500A | SRL-Z300/600A | SRL-Z500/1000A |
| TOTAL VOLUME(L) | 50/100 | 110/200 | 200/500 | 300/600 | 500/1000 |
| EFFECTIVE VOLUME(L) | 37/70 | 75/130 | 150/320 | 225/384 | 375/640 |
| BLADE RATE(rpm) | 510/1013/118 | 650/1300/130 | 484/967/110 | 480/964/100 | 413/830/71 |
| MOTOR POWER(Kw) | 7/11/7.5 | 14/22/11 | 30/42/11 | 40/55/11 | 47/67/15 |
| HEATING POWER/COOLING MEDIUM | 2KW | 6KW | 6KW | 9KW | 9KW |
| UNLOADING WAY | PNEUMATIC | ||||
| WEIGHT(T) | 2.8 | 3 | 3.5 | 3.8 | 5.8 |
