Home > Products > Plastic crusher > PE PP waste plastic lump crusher
PE PP waste plastic lump crusher
- 10 Set / Sets per Month
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | SEVENSTARS | |
| Use | Plastic Pipe Crusher | Plastic Type | PP/PE | |
| Shaft Design | Single | Capacity | depend on customer |
Product Description
Specifications
Plastic lump crusher1. can recyle various kind plastic waste
2. shredding and crushing are integrated in one system
Plastic lump crusher's application:
It’s used to recycling waste plastic lump, plastic pipe etc. according to material's shape, we have light duty crusher and heavy dutry shredder to you to choose.
.
Process technology of heavy duty plastic lump shredding/crushing:
plastic Waste lump —> shredding machine —> Conveyor —> Crushing machine —> Suction out PE granules
Technical sepcification of intergrated shredder/crusher for plastic waste lamp:
Shredder | |
Drive part | Main motor: 22kw |
Reducer: hard gear tooth face gearbox | |
Shredding part | Static blade: 1pcs |
material: SKD-11(very good material) | |
dynamic blade:26pcs | |
material: SKD-11(very good material) | |
Main rotor rotating speed | 83r/min |
Main rotor | Rotating diameter: 220mm |
Effective working length:600mm | |
Hydraulic system | Oil pump power: 1.5kw |
Max working pressure: 10Mpa | |
Oil temperature cooled by water | |
Pushing material part | controlled by PLC |
Max distance controlled by approach switch | |
Electric components | PLC: DELTA Others: DELIXI |
Crusher | |
Rotation diameter | 260mm |
Dynamic blades | 12pcs |
Static blades | 2pcs |
Screen hole diameter | 10mm |
Motor power | 7.5kw |
Material Suction blower | 2.2kw |
