C6132A universal lathe machine price with high precision
USD $5,000 - $50,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Shenzhen Shanghai Qingdao Guangzhou
- T/T L/C D/P D/A Credit Card
You May Like
-
CN-K40D/1000 CNC lathe machine for sale
-
CW6263B Horizontal saddle bed lathe machine for sale
-
CW6163C/3000 Horizontal Lathe Machine for sale
-
Universal lathe machine CW6163B/7000
-
C5123/1250 Heavy Duty Conventional single column Vertical Lathe
-
Special discount for lathe. High quality CNC metal turning lathe with with large turning diameter and short bed CAK6456
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 360mm | Place of Origin | Guangxi, China | |
| Brand Name | Guangxi Xiashi | Model Number | C6132A | |
| Voltage | Customer's Requirement | Power(W) | 3KW | |
| Dimension(L*W*H) | 2290/2575mm*1100mm*1465mm | Weight | 1300kg | |
| Certification | CE ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
C6132A universal lathe machine price with high precision
Product Description
Features
C6132A High Precision and Heavy Duty Industrial Lathe
1,Max.swing over bed :360mm
2.Spindle bore :46/52mm
Specification
| Model | C6132A | C6232A | C6140A | C6240A |
| Center height | 180mm | 180mm | 202mm | 202mm |
| Max.swing over bed | Φ360mm | Φ360mm | Φ400mm | Φ400mm |
| Max.swing over carriage | Φ200mm | Φ200mm | Φ245mm | Φ245mm |
| Max. swing over gap | 540mm | 585mm | ||
| Effective gap length | 200mm | 200mm | ||
| Center distance | 750mm/1000mm | |||
| Width of bed | 330mm | |||
| Spindle bore | Φ46mm/52mm | |||
| Taper of spindle bore | M.T.#6 | |||
| Range of spindle speed | 25-1600rpm | |||
| Cross | 240mm | |||
| Compound | 140mm | |||
| Max. travel | 130mm | |||
| Taper of inside | M.T.#4 | |||
| The power of main motor | 3/4.5kw | |||
| Range of metric number | 30kinds 0.4-20mm | |||
| Inch | 35kinds 80- | |||
| Diametric pitch | 30kinds 160-3 D.P. | |||
| Module | 25kinds 0.25-10mm | |||
| Feed change | 138 steps | |||
| Long feed per spindle rev | 0.04-2.15mm | |||
| Cross feed per spindle rev | 0.02-1.08mm | |||
| N.W/G.W | 1300kg/1400kg | |||
| Packing size | 2290/2575mm×1100mm×1465mm | |||
Pictures for your reference
Packing&Delivery&Terms of Payment
We use wooden package to protect the equipment in container.
Why Choose Us?
- We have our own factory and strong production capacity.
- we insist on good quality and have strict quality standards
- The hiring of experienced staff to guarantee high quality.
- Our product can be made as per your requirement .
- 24 hour online communication for you.
- We have more than 6 years of export experience.
FAQ
Q: What information should I let you know, if I want to get a product offer?
A: 1. the size of your work piece
2. the CNC system you preferred if you need CNC type
3. the work piece drawing if you have
Q: How to control the quality of production processes?
A: We have a professional quality inspectors to check on the quality of the finished product.
Q: Is it possible to visit your factory?
A: It is very convenient to visit us and all clients from around the world are highly welcomed.
Q: What’s the MOQ?
A: The MOQ is 1 set.
Q: What’s the quality assurance and service ?
A: We offer one year warranty and 100% quality inspection before shipment. We shall reply your message within 24 hours to solve your problem.
