Machine for Hvac Spiral Duct
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Pipe Molding Machine | |
| Pipe Material | Other, Galvanzied steel | Application | Other, HVAC Duct | |
| Production Capacity | 20-35m/min | Place of Origin | Jiangsu, China | |
| Brand Name | BOBO | Model Number | BTF-I | |
| Voltage | 380V | Power(W) | 9.5KW | |
| Dimension(L*W*H) | 2000X1800X1450 | Weight | 2200KG | |
| Certification | CE | Warranty | one year |
Product Description
Specifications
Machine for hvac spiral duct1- diameter 80-1000
2- thickness 0.4-1.0mm
3- tracking-saw cutter
4- unloading rack
Machine for hvac spiral duct
The spiral duct forming machine BTF-I is used to produce the round rigid air duct for ventilation purpose, diameter from 80-1000mm, with wall thickness 0.4-1.0mm galvanized steel.
Feature
1. Special aluminum alloy mould, light & long life
2. Round roller shear, without noise and burrs
3. Large diameter range
4. PLC control, convenient operation
5. Auto unloading rack, low labor cost
Main configuration
1 Uncoiler: mechanical expanding type, capacity 1500kg, inner diameter range 480-610mm, outer diameter 1000mm.
2 Control system: Mitsubishi inverter, PLC control
3 Driving system: Spiral subulate gear type decelerator (low noise, large moment)
4 Material of forming rollers: GCr15 bearing steel, quenched, HRC58-62
Key words: BTF-I spiral tubeformer, spiral duct forming machine, ventilationd duct machine, spiral tube former, spiral duct former, ventilationd duct machine, HVAC duct machine, air duct machine.
