Home > Products > toggling machine > 6'x3'china Cheaper Small Second Tannery Machine Toggle Machine
6'x3'china Cheaper Small Second Tannery Machine Toggle Machine
- Shanghai
- T/T Credit Card PayPal
You May Like
-
Leather Machine for Frog or Fish
-
Manual Leather Toggling Drying Machine Supplier
-
20m Goat Sheep Skin Automatic Toggling Machine
-
20m Length 2.2m Width Leather Automatic Stretching Dry Machine
-
Tannery Machine Leather Italy Quality China Price 20m Automatic Stretching Dry Machine
-
China Tensile Stretching Test Machine for Leather
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | DCH | |
| Model Number | second Tannery machine, second Tannery machine | Type | Other, second Tannery machine | |
| Voltage | 380 | Power(W) | 50 | |
| Dimension(L*W*H) | 3600x2500x2000 | Weight | 2500 | |
| Certification | ISO | Warranty | one | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
second Tannery machine key word
1.small size toggling
2.lower temp finalize the design
3.steam,natural gas as recycling hot energy
4.toggling dry the carton
Technical parameters of second Tannery machine
No | Part | Detail |
1 | Working area | 2m to 1m |
2 | Toggling number | 20 |
3 | Number for leather for stretch once time | 1000 pcs |
4 | Max temp of oven | 60 degree |
5 | Steam pressure | 0.4-0.6mpa |
6 | Steam consumption | 30L/h |
7 | Air pressure | 4-6h |
8 | Drying time | 0-150mm |
9 | Range for stretch | Max more 4 person |
10 | Operate worker | 11kw |
Material of second Tannery machine
No | Machine part | Description |
1 | Machinery structure | Square pipe weld for dry room, square pipe size:50x50x2, 50x30x2mm |
|
| Steel with foam for outside structure , 50mm thickness |
2 | Toggling structure | Seamless tube n60x4mm, steel pipe n48x4mm,square pipe 40x40x3.5mm, Weld together for toggling |
3 | Toggling screen | Steel 1.8mm punching into screen |
4 | Guide system | Each toggling distance is 160mm,guide steel :80x8mm,pulley make the guide system |
5 | Guide crossbirdge | Weld by 50x30x2.5mm square pipe,10# and 12# u-steel with 50x30x2.5mm square pipe,5#angle iron,8mm A3 steel make up |
6 | Dry system | The steam as heat source,bolwer (0.75kw,diameter 500mm fan blade),radiator make the dry device.
|
7. | energy | steam ,gas,electric ,hot oil |
second Tannery machine leather type
crocodile,Steer hide,cow,crown,dog skin,saffian,sheep,Wool skin,Cow hide,Calf skin,Kangaroo,Kid skin
Kip skin,Cattle hide,Glace kid,Deer skin,Water buffalo hide,chamois
second Tannery machine buyer
France ,Indonesia ,Pakistan , India ,Mongolia ,Malaysia and so on
second Tannery machine Spare parts supply
Item | Name | Q’ty |
1 | All air parts | 1 set |
2 | Electric valve | 1 set |
3 | Limited switch | 2pcs |
4 | Travel switch | 2pcs |
5 | Motor | 2 pcs |
6 | contactor | 2pcs |
7 | Operate Tool | 1 Set |
