China Cheaper 1600 to 3200mm Leather Vibration Staking Machine
- Shanghai
- T/T
You May Like
-
Leather Process Machine of Staking Machine for Tannery
-
Leather Process Machine 1600 to 3200mm 2 or 3 or 4 Head
-
Staking Machine for Machines Tannery for Sale
-
Sheep Goat Cow Crust Skin Machine Leather Staking Machine 1600 to 3200mm Leather Vibration Staking Machine
-
Tannery Machine of Vibration Staking Machine Exporter
-
China Tannery Machine of Vibration Staking Machine
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | DCH | |
| Model Number | leather vibration staking machine | Type | Other, leather vibration staking machine | |
| Voltage | 380 | Power(W) | 40 | |
| Dimension(L*W*H) | 3500x2500x2000 | Weight | 3000 | |
| Certification | ISO | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
leather Vibration staking machine1.auto remove rease
2.auto air dusty collect
3.auto oil lubration system
leather vibration staking machine key point
1. Auto lubricating system
2. Auto remove crease unit
3. Auto air dusty collector
4. PLC control all system
leather vibration staking machine Specification
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-4 head | 1600mm | 600t/m | 0-20m/min | 22kw | 3.5-4.5mpa | 2220x2970x1610 | 11000kg |
2400-4 head | 2400mm | 600t/m | 0-20m/min | 29.7kw | 4.5-5.5mpa | 3020x2970x1610 | 15000kg |
3200-4 head | 3200mm | 600t/m | 0-20m/min | 29.7kw | 4.5-5.5mpa | 3820x2970x1610 | 18000kg |
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-3 head | 1600mm | 600t/m | 0-20m/min | 23.4kw | 3.5-4.5mpa | 2220x2970x1610 | 9000kg |
2400-3 head | 2400mm | 600t/m | 0-20m/min | 30.4kw | 4.5-5.5mpa | 3020x2970x1610 | 11000kg |
3200-3 head | 3200mm | 600t/m | 0-20m/min | 38.4kw | 4.5-5.5mpa | 3820x2970x1610 | 14000kg |
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-2 head | 1600mm | 600t/m | 0-20m/min | 9kw | 3.5-4.5mpa | 2220x2970x1610 | 6500kg |
2400-2 head | 2400mm | 600t/m | 0-20m/min | 12.5kw | 4.5-5.5mpa | 3020x2970x1610 | 7500kg |
3200-2 head | 3200mm | 600t/m | 0-20m/min | 17.2kw | 4.5-5.5mpa | 3820x2970x1610 | 9000kg |
leather vibration staking machine key parts picture
leather vibration staking machine part brand
No | Part | Brand list |
1 | BEARING | JAPAN |
2 | Hydraulic pump | JAPAN |
3 | Breaker | JAPAN OR FRANCE |
4 | Contactors | JAPAN OR FRANCE |
| 5 | thermal relay | JAPAN OR FRANCE |
| 6 | air base | GERMANY |
| 7 | cloth | ITALY |
| 8 | valve | JAPAN |
leather vibration staking machine Certificate
