portable rail drills press portable boring machine tools for Italy
- 1000 Set / Sets per Month
- Qingdao port or others
- T/T Credit Card PayPal
You May Like
-
portable rail drills press portable boring machine tools for Italy
-
Electric rail bonding drill / rail driller for railway maintenance
-
Steel Rail Drilling Machine with high drilling precision
-
HOT sales Lifting capacity 5-15t rack lifting jack for rail
-
hydraulic track jack rail jack track lifting jack
-
10T steel rail lift mechanical jack ,track jack,rail lifting jack
Product Details
| Type | Tie Plates | Material | Carbon Steel | |
| Dimensions (L x W x H) (mm) | Customer's Drawing | Place of Origin | Shandong, China | |
| Brand Name | QK | Model Number | KKY-500 |
Product Description
portable rail drills press portable boring machine tools for Italy
A, KKY hydraulic squeeze hole machine the main components:
Hydraulic squeeze hole machine from the rack and hydraulic two major components.
1, frame parts: the die 2 and punch 3, the guide sleeve 5, the guide sleeve seat 6, adjusting screw 8, swivel 11, the head 12, the positioning gear 16, the arm 18, the arm 21, the spindle 22, Horn 27, lift hand 42, a joystick 45, articulated return, return the articulation screws and other components.
2, hydraulic parts: the return valve screw assembly, piston rod, piston, cylinder, pump seat, pump sets, pump core, composed pipeline tubing fittings, ball valves and other components out of steel.
Two, KKY hydraulic squeeze hole machine detailed parameters:
KKY-300 type for 30KG / m of rail extrusion hole, maximum drilling diameter of 24mm, maximum punching thickness 12mm, maximum punch force of 85T, KKY-500 type for 15KG / m ~ 24KG / M rails squeeze hole, maximum drilling diameter of 22mm, maximum punching thickness 11mm, maximum punch force of 50T, KKY-1050 type for 30KG / m ~ 50KG / M of rail extrusion hole, maximum drilling diameter of 31mm, maximum punching a thickness of 15.5mm, the maximum punch force 105T.
Third, hydraulic squeeze hole machine role:
Hydraulic rail extrusion hole machine (punch) the use of leverage, hydraulic transmission, and shear principle designed. The use of static pressure to squeeze the hole on the rail operations. One minute to play a hole, the product has reasonable structure, easy to carry, easy operation, good sealing performance oil passage, hydraulic stability, and reduce labor intensity and improve work efficiency, improve the track construction, maintenance quality, extend rail life and other characteristics of railway rail essential tool to standardize operations.
Jining City Green Branch Machinery Co., Ltd. specializes in the production of railway rail transportation equipment, mining equipment: hydraulic track machine, rack from the road machine, manual machine from the road, hand from the road machine, hand across the top, hydraulic lining machine, electric rail cutting machine, claw jack, hydraulic bending rail, hydraulic curve, the locomotive off the track reset, electric saws track machines, electric drilling machines, hydraulic squeeze hole machine, hydraulic Puller (hydraulic Rama), hydraulic lift column, hydraulic prop and so on
Packaging: wooden case or as client requires
Shipping: within 5 days after received the deposit.
1.Supply item design,process design.
2.Help you to chose the fit machine.
3.Making the machine according to your requirement.
Sale Service
1.Acceptance equipment together with you.
2.Help you to make the method statement and the details of the process.
After Service
1.Guarantee for a year.
2.Quality problem,we will send you the accessories.
3.Free repair whole using life(without the freight and accessories charge).
Jining Qingke Machinery Co.,Ltdestablished in July 29, 2015, registered capital of 5 million . this is our new branch. Our factory has 6 years history. We have CNC machining center, CNC lathe,boring machine,and milling machine.
Main products: steel bar cutting machines, bending machines,straightening and cutting machines, electric vibration impact machines, ground polishing machines, terrazzo machines, adjustment electric hoisting machines.Solar water pump.Garden Machinery including tree spade , lawn mower, Construction machinery and accessories, Road Marking and Mining equipment, Mining tools and so on.
we passed the ISO9001:2000 certification. Our company products have been exported to Europe, Russia, south America, Africa,more than 20 countries.
