magnetic Induction bearing heater puller
- Qingdao/Shanghai
- T/T Credit Card
You May Like
-
SKF TIH High quality cast aluminum Shell Bearing heater 3.6 KVA/230V
-
SKF TIH 3.6 kva bearing heater with Swivel arms portable with wheel
-
SKF Heavy Duty bearing heater for Mining equipment and Oil Equipment
-
3.6KVA induction heater for bearing/gear/sleeves assembly
-
SMBG Induction Heater For Bearings Mount And Dismount
-
induction gear ring puller induction bolt heating machine
Product Details
| Condition | New | Type | Duct Heater | |
| Power Source | Electric | Place of Origin | Shandong, China | |
| Brand Name | QK | Model Number | SMBG | |
| Dimension(L*W*H) | 260*240*260 | Weight | 12.5kg | |
| Voltage | 220V, 110, 220,380v | Power(W) | 2.5kw, 4.5kw | |
| Certification | CE,ISO | Warranty | 2 Years | |
| After-sales Service Provided | No overseas service provided |
Product Description
save energy electric magnetic induction wheel gearing heating tools
Description:
- Improve assembly quality, even heating, high precision, keep surface harness constant;
- Improve work efficiency, quick heating speed, reduce works strength, improve assembly progress, reach to the aim of civilized production;
- Rational and advanced in structure, easy, safe, reliable to operate with fire danger;
- Save energy sources, reduce cost, improve profit, saving 100% oil compared with oil induction heating, save 60% oil compared with electric furnace;
- After stopping heating, ZJ series induction heater will automatically demagnetize below 0.8mt, which conforms to ZJS-004 standard. So it is the best induction heater equipment for civilized production, high-efficiency production and safe production.
Parameter For Induction Bearing Heater:
Model | SMBG-1.0 | SMBG-2.0 | SMBGW-2.0 | SMBG-3.6 | SMBG-3.6 |
Capacity(KVA) | 1.0 | 2.0 | 2.0 | 3.6 | 3.6 |
voltage(V) | 110/220V | 110/220V | 110/220V | 220/220V | 220/220V |
Column dimension(mm2) | 30×30 | 40×40 | 40×40 | 60×60 | 60×60 |
Column height(mm) | 60 | 110 | 110 | 150 | 150 |
inner diameter(mm) | φ > 15 | φ > 15 | φ > 15 | φ > 30 | φ > 30 |
outer diameter(mm) | 150 | 200 | 400 | 500 | 500 |
Max.bearing width(mm) | 55 | 110 | 145 | 140 | 140 |
Max.bearing weight(KG) Other part | 105 | 2015 | 20 15 | 30 20 | 30 20 |
Temperature control (Digital display) | 50-240℃ | 50-240℃ | 50-240℃ | 50-240℃ | 50-240℃ |
Time contro l(Digital display) | 99Minutes 59seconds | 99Minutes 59seconds | 99Minutes 59seconds | 99Minutes 59seconds | 99Minutes 59seconds |
Sound signal | Yes | Yes | Yes | Yes | Yes |
The error operation | (Digital display) | (Digital display) | (Digital display) | (Digital display) | (Digital display) |
Keep the temperature | Yes | Yes | Yes | Yes | Yes |
Automatic demagnetization | Yes | Yes | Yes | Yes | Yes |
Dimension(cm) | 32×19×20 | 42×19×28 | 32×32×25 | 32×32×32 | 32×32×32 |
Heating rod standard(mm) Heating rod matching(mm) | 10,20,30 | 10,24,40 | 10,24,40 | 20,30,40,60 | 20,30,40,60
|
Rotating device | No | No | No | No | With a rotation arm |
Delivery time for order within available stock is in 7days
Delivery time for order without available stock is in 15days
Pre-sale Service
1.Supply item design,process design.
2.Help you to chose the fit machine.
3.Making the machine according to your requirement.
Sale Service
1.Acceptance equipment together with you.
2.Help you to make the method statement and the details of the process.
After Service
1.Guarantee for a year.
2.Quality problem,we will send you the accessories.
3.Free repair whole using life(without the freight and accessories charge).
