Specifications

Common Applications

• Pressure washers
• Commercial lawn and garden equipment
• Tillers / cultivators
• Generators
• Construction / industrial equipment
• Agricultural equipment
• Water pumps
• Specs

• Engine Type	Air-cooled 4-stroke OHV
  Bore x Stroke	68 X 45 mm
  Displacement	163 cm3
  Net Power Output*	4.8 HP (3.6 kW) @ 3,600 rpm
  Net Torque	7.6 lb-ft (10.3 Nm) @ 2,500 rpm
  PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
  Compression Ratio	9.0 : 1
  Lamp/Charge coil options	25W, 50W / 1A, 3A, 7A
  Carburetor	Butterfly
  Ignition System	Transistorized magneto
  Starting System	Recoil Starter
  Lubrication System	Splash
  Governor System	Centrifugal Mechanical
  Air cleaner	Dual Element
  Oil Capacity	0.61 US qt. (0.58 L)
  Fuel Tank Capacity	3.3 U.S. qts (3.1 liters)
  Fuel	Unleaded 86 octane or higher
  Dry Weight	33 lbs. (15.1 kg)

  Dimensions
  Length (min)	12.2" (312 mm)
  Width (min)	14.3" (362 mm)
  Height (min)	13.6" (346 mm)

  PTO Shaft Options
  H type	Reduction type PTO
  L type	Reduction type PTO
  Q type	Straight shaft
  R type	Reduction type PTO
  S type	Straight shaft (metric)
  T type	Straight shaft
  V type	Tapered shaft

•                  Performance Curve

•

                   Features

•

  Available Options

  • Low profile versions
  • Gear reduction options
  • Electic start
  • Spark arrester available
  • Charge and lamp coils with multiple output options available
  • Cyclone Air Cleaner available
