PYB/D/Z series Spring Cone Crusher for crushing stones high efficient

   Spring cone crusher is applied to process above medium hardness ore stone and rock. Its spring insurance system is overload protection to protect machine from damage of metal, grease and water seal are adopted, segregating stone powder and grease to guarantee stable working performance. This type of crushing chamber depends upon the purpose of mineral . The standard type (PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to hyper fine crushing. Spring cone crusher is widely applied in metallurgy, construction, white fuel, transportation, chemical engineering and construction material to process above medium hardness ore stone and rock, it has many advantages like reliable structure, high capacity, easy to adjust, low cost, and so on.

Model	Diameter of Bottom End of Conical Crushing Head(mm)	Max Feeding Size(mm)	Adjustable Range of Discharge Opening(mm)	Capacity(t/h)	Motor Power(kw)	Rev.of Eccentric Shaft(r/min)	Weight(t)	Dimension (L×W×H)(mm)
PYB600	Φ600	75	12-15	20-40	8P-30	356	5	2234×1370×1675
PYD600	Φ600	35	3-13	12-23	8P-30	356	5.5	2234×1370×1675
PYB900	Φ900	115	15-50	50-90	8P-55	333	11.2	2692×1640×2350
PYZ900	Φ900	60	5-20	20-65	8P-55	333	11.2	2692×1640×2350
PYD900	Φ900	50	3-13	15-50	8P-55	333	11.3	2692×1640×2350
PYB1200	Φ1200	145	20-50	110-168	8P-110	300	24.7	2790×1878×2844
PYZ1200	Φ1200	100	8-25	42-135	8P-110	300	25	2790×1878×2844
PYD1200	Φ1200	50	3-15	18-105	8P-110	300	25.3	2790×1878×2844
PYB1750	Φ1750	215	25-50	280-480	8P-160	245	50.3	3910×2894×3809
PYZ1750	Φ1750	185	10-30	115-320	8P-160	245	50.3	3910×2894×3809
PYD1750	Φ1750	85	5-13	75-230	8P-160	245	50.2	3910×2894×3809
PYB2200	Φ2200	300	30-60	590-1000	8P-(260-280)	220	80	4622×3302×4470
PYZ2200	Φ2200	230	10-30	200-580	8P-(260-280)	220	80	4622×3302×4470
PYD2200	Φ2200	100	5-15	120-340	8P-(260-280)	220	81.4	4622×3302×4470





Nude packing for the main machine

Wooden case for the power motor and spare parts

       We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support  and after service.

      Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.

Our main scope of our business:

Machinery and Equipment:

Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment

Power Transmission Parts

Chains, sprockets, taper bushes, gears and shafts

OEM components:

Machined, forged, cast, punched and welded workpiece

Micro Motors

Step motors, DC brushed & brushless motors, AC motors for aircon and paper shredder

Automobile Accessories

Auto lens and lamps, mirrors, motors and mechanical parts

Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders.
