CE and ISO Certified AMEC High Quality Impact Crusher , Mini Stone Crusher

    Impact crusher is the most advanced crushing machine combining domestic stone&sand industry specific situation, and it absorbs latest technology. It adopts advanced production technique and unique structure design, final product shape would be cube, max input size of material should be 500mm, compressive strength should be less than 350MPa, all kinds of coarse, medium, and fine size material(granite, limestone and concrete) could be processed. Impact crusher is widely applied in mining, railroad, highway, energy, cement, chemecal, construction industries. Final size of material could be adjusted, double chamber and triple chamber types are available, unique structure adopt keyless connection, high chrome hammer, and special impact plate; crushing process is simplified, makeing it more energy-efficient; Cube final product shape,and adjustable discharge size.

Model	Specification(mm)	Feed Opening(mm)	Max.Feeding Size(mm)	Capacity(t/h)	Model of Motor	Power (kw)	Weight(t)	Overall Dimension (L×W×H) (mm)
PF-1007	Φ1000×700	400×730	300	35-50	Y250M-6	37	9.5	1800×1600×1800
PF-1010	Φ1000×1050	400×1080	350	50-80	Y315S-6	75	14	2340×2007×2500
PF-1210	Φ1250×1050	400×1080	350	70-120	Y315L1-6	110	17	2582×2053×2809
PF-1212	Φ1250×1200	400×1250	350	70-140	Y315L2-6	132	17.5	2582×2203×2809
PF-1214	Φ1250×1400	400×1430	350	80-160	Y315L2-6	132	22	2582×2403×2809
PF-1315	Φ1300×1500	680×1520	350	90-220	Y2-355M2-6	200	26	2930×2761×3053
PF-1320	Φ1300×2000	680×1570	350	110-350	Y2-355M2-6	280	28	3340×2950×3000



Nude packing for the main machine

Wooden case for the power motor and spare parts

       We have office oversea we can easy to privide the csutomer about befroe sales service, machine quality control service ,technical support  and after service.

      Changzhou Machinery and Equipment Import and Export Co., Ltd. (AMECCO) ()was founded in 1983. Taking advantage of the ownership of our six manufacturing subsidiary companies, we share our benefits in production and technology with our clients while we focus on the import and export of commodities and service. Strict quality control system, timely delivery and customer-oriented service make us have established trade relations with clients in more than 70 countries and regions.

Our main scope of our business:

Machinery and Equipment:

Power machinery, agricultural machinery, garden machinery, construction machinery, mining machine,machine tools and complete equipment

Power Transmission Parts

Chains, sprockets, taper bushes, gears and shafts

OEM components:

Machined, forged, cast, punched and welded workpiece

Micro Motors

Step motors, DC brushed & brushless motors, AC motors for aircon and paper shredder

Automobile Accessories

Auto lens and lamps, mirrors, motors and mechanical parts

Keeping the customers satisfied has been our strong wish. Please contact us for more information. We welcome your orders.
