Home > Products > ZL12 Series Wheel loader with CE > mini wheel loader ZL12F
mini wheel loader ZL12F
- Qingdao Port
- T/T
You May Like
Product Details
| Condition | New | Brand Name | SWLTD | |
| Model Number | ZL12F | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 4800*1730*2720 | Rated Load | 1200kg | |
| Certification | CE BV ISO | Warranty | 1 year or 1000 working hours | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
mini wheel loader with ce1)CE mark
2)Changchai or Cummins Engine
3)Quick hitch,pallert fork
4)SEMTorque Convert
Features
1. The mini loader uses a hydro-mechanical transmission which can make full use of engine power, and can have an automatic variable transmission according to the external resistance. It avoids power failure of the engine due to the suddenly increased external load.
The mini loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, and facilitates the operation and achieves higher economical and production efficiency.
2. The mini loader uses the central articulated frame and load sensing hydraulic steering gear. The machine can achieve short turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving). The wheel loader has the advantages of easy operation on narrow sites, flexible operation, safety, convenient maintenance and so on.
3. The mini loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good trafficability and larger traction.
4. The mini loader is equipped with a single-pipe type hydraulic four-wheel brake.
5. The mini loader has a fully enclosed cab and the seats have the functions of vibration reduction and easyadjustment. The mini loader offers the driver a comfortable drive and wide view.
Technical Specifications
Main Technical Parameter of ZL12F | |
| Item | Parameter |
| Rated load (kg) | 1200 |
| Bucket capacity (m3) | 0.6 |
| Wheel tread (mm) | 1400 |
| Wheel base (mm) | 2005 |
| Min turning radius (mm) | 4500 |
| Min ground clearance (mm) | 260 |
| Dumping height (mm) | 2650 |
| Corresponding dumping reach (mm) | 1020 |
| Lifting time (s) | 4 |
| Hydraulic cycle time (s) | 8.5 |
| Maximum excavating force (KN) | 36 |
| Drive mode | Four are Drive |
| Machine weight (kg) | 3100 |
| Overall dimensions (mm) (Length*width*height) | 4800*1730*2720 |
| Engine model | Changchai4L68 |
| Rated power of engine (kw) | 37 |
| Rated speed of engine (rpm) | 2200 |
We are the professional and big manufacturer of the loaders and forklifts for over 17 years .
Our main products are as follows:
800kg wheel loader ZL08A ZL08B
1000kg wheel loader ZL10A ZL10B ZL10F SWM610
1200kg wheel loader ZL12F (best sell model) SWM615 SWM618
1600kg wheel loader ZL16F
2000kg wheel loader SWM620
3500kg wheel loader SWM635
5000kg wheel loader SWM952
Rough Terrain Forklift --Hot Sale
2800kg CPCY28
3500kg CPCY35
5000kg CPCY50
10000kg CPCY100
Diesel Forklift
3000kg and 3500kg CPC30 CPC35
Electric Forklift
1500kg CPD15
It is our great pleasure to receive your specific inquiries .
Please send us inquiries or send email to directly .
Our best wishes to you and your esteemed company . :) O(∩_∩)O
