Home > Products > high altitude operation truck > Dongfeng 4*2 telescoping bucket crane truck sale
Dongfeng 4*2 telescoping bucket crane truck sale
- Shanghai
- T/T Credit Card
You May Like
-
JMC folding arm High-altitude Operation Truck for hot sale,high lifting platform truck
-
JMC 14m folding arm High-altitude Operation Truck for hot sale
-
JMC High-altitude Operation Truck,high altitude operation truck,high up truck
-
JMC High lifting platform truck for hot sale,high altitude equipment
-
JMC hydraulic aerial cage with good quality,high altitude work vehicle
-
JMC overhead working truck,aerial platform truck,high lifting platform truck
Product Details
| Transmission Type | Manual | Condition | New | |
| Emission Standard | Euro 3 | Fuel Type | Diesel | |
| Dimensions (L x W x H) (mm) | 7400*1980*3110mm | Place of Origin | Hubei, China | |
| Brand Name | Dongfeng | Model Number | CLW5040JGKZ3 |
Product Description
Dongfeng 4*2 telescoping bucket crane truck sale
Main technical parameters:
Vehicle model | CLW5040JGKZ3 | |
Type | High altitude operation truck | |
Overall dimensions(mm) | 7400×1980×3110 | |
Gross vehicle gross(kgs) | 4325 | |
Working Cage | Internal size(mm) | 1100×600×1100 |
Rated loading(kg) | 200(or 2 persons) | |
Max. Working height(mm) | 20000 | |
Max. Height from ground(mm) | 12300 | |
Max. Working radius(mm) | 7050 | |
Working radius when doing the highest height(mm) | 2990 | |
Working Boom | Max. Raising angle of lower boom(º) | 70 |
Max. Raising angle of upper boom(º) | 70 | |
Max. Raising angle of jib(º) | 90 | |
Boom rack rotation angle(º) | 360 | |
Outrigger | Vertical span(mm) | 2950 |
Horizontal span(mm) | 2750 | |
Travelling of vertical outrigger(mm) | 450 | |
Adjustment | Single adjustable | |
Lifting | Rated lifting weight(kg) | 995 |
Rated lifting height(mm) | 7700 | |
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
Reference Picture:
