23900L Chemical Liquid Tanker Truck

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Storage	Chemical
Drive Wheel	8x4	Horsepower	251 - 350hp
Transmission Type	Manual	Fuel Type	Diesel
Tank Volume	15001 - 30000L	Engine Capacity	9726ml
Dimensions (L x W x H) (mm)	1198025003650	Brand Name	CLW
Place of Origin	Hubei, China	Model Number	CLW5310GYYZ3
Gross Vehicle Weight	31000

Product Description

Specifications

23900L chemical liquid tanker truck
1>Effective cubage:23900L
2>Engine power: 270hp
3>Drive type: 8*4

23900L chemical liquid tanker truck

VEHICLE PARAMETERS :

Product	23900L chemical liquid tanker truck
Vehicle model	CLW5310GYYZ3
Chassis model	ZZ1317M4669V
Chassis parameters	Overall dimensions	mm	11980×2500×3650
	Gross weight	kg	31000
	Kerb weight		14870
	Rated payload		16000
	Suspension F/R	mm	1500/2730
	Wheel base		1800+4600+1350,1800+4575+1400
	Drive type		8*4
	Number of axles		4
	Axle-load	Kg	6500/6520/17980
	Number of Spring leafs		left14right13/left14 right13/12,11/11/12,4/4/-,11/11/-
	Tire specification		11.00-20,12.00-20
	Number of Tires		12
	Allowable passengers in cab		2
Engine	Engine model		WD615.92
	Type of fuel		Diesel
	Displacement/power	ml/hp	9726/270
	Max speed	Km/h	85
	Emission standard(TAS)		EURO 3
Tank	1.Effective cubage: 23900L 2.Tank dimensions: 9000×2350×1650mm 3.Material: high quality carbon steel, stainless steel, glass steel or plastic steel

Payment terms and delivery:

Delivery date: 7-10 days

Payment terms: 30% TT as deposit and 70% TT upon receipt of B/L copy

Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements

Remarks:

The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.

Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
