16t Heavy Duty Horizontal Lathe Machine
- China port
- T/T
You May Like
-
SL Series Heavy Duty Horizontal Lathe Machine For Sale
-
190mm Swing Heavy Duty Horizontal Lathe Machine For Sale ( DL-1900 )
-
Precision Gap-bed TORNOS CL-800S
-
Universal Metal Centre Lathe CZ6266C
-
630 - 940mm Swing Horizontal Gap Bed Lathe Machine With Low Price
-
800 mm Swing High Precision Horizontal Gap Bed Lathe Machine For Sale (TORNOS-6280C)
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 1250mm-2000mm | Brand Name | TIMAC | |
| Model Number | AL-1250 / AL-1600 / AL-2000 | Voltage | as customer's request | |
| Power(W) | 30 kw | Weight | 1600kg | |
| Certification | CE & ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
"16 tons load-bearing "Heavy Duty Horizontal Lathe Machine For Sale (AL-1250/AL-1600/AL-2000)
Features :
1. This heavy duty lathe adopts 1100mm wide rectangular induction hardened and ground bed guide ways , so of excellent stablity , high rigidity , and with maximum bearing of 16 tons between centers.
2. The main spindle is of precision roller bearings 3-point supporting structure. Saddle guide ways with Teflon belt coated coated . Rotating tailstock quil structure to minimize friction and heat generation .
3. These machines are suitable for various turning works , such as turning of external and internal cylindrical surfaces end faces , and turning of metric or inch threads , modular threads and diametrical pitch threads , ect..
4. Motorized short taper turning could be done by the top slide independently , and long taper's motorized turning could be done by top slide combined with longitudinal feed . Further more , these machines can also carry out drilling , trepanning and boringprocesses , ect..
Parameter :
Specification | Unit | AL-1250 | AL-1600 | AL-2000 |
Swing over bed | mm | 1250 | 1600 | 2000 |
Swing over cross slide | mm | 900 | 1250 | 1650 |
Max. length of workpiece | mm | 3000/4000/5000/6000/8000/10000/12000/14000/16000/18000 | ||
Max. turning length | mm | 2800/3800/4800/5800/7800/9800/11800/13800/15800/17800 | ||
Width of bed | mm | 1100 | ||
Spindle nose |
| A2-15 | ||
Spindle bore | mm | 100 | ||
Taper hole of spindle |
| metric 140 | ||
Spindle speeds (forward) | rpm | 21 kinds, 3.15~315 | ||
Spindle speeds (reverse) | rpm | 12 kinds, 3.5~291 | ||
Longitudinal feed range | mm/r | 56 kinds, 0.1~12 (0.004"~0.473") | ||
Cross feed range | mm/r | 56 kinds, 0.05~6 (0.002"~0.236") | ||
Upper tool-post range | mm/r | 0.025~3 (0.001"~0.118") | ||
Number and range of metric thread | mm | 44 kinds, 1~20 | ||
Number and range of inch thread | TPI | 31 kinds, 28~1/4 | ||
Number and range of module thread | mm | 45 kinds, 0.5~60 | ||
Number and range of diametrical pitch thread | DP | 38 kinds, 1/2~56 | ||
Rapid travel speed (longitudinal) | mm/min | 3740 | ||
Rapid travel speed (transverse) | mm/min | 1870 | ||
Rapid travel speed (top slide) | mm/min | 935 | ||
Distance between spindle center-line and tool resting plane | mm | 53 | ||
Section of tool shank | mm | 50 | ||
Tool post swing range |
| ±90º | ||
Max. travel of tool post | mm | 300 | ||
Max. travel of cross slide | mm | 740 (29") | 850 (33") | 900 (35") |
Tool post travel per turn of the dials of top or cross slide | mm | 0.05 (0.002") | ||
Diameter of tailstock quil | mm | 260 | ||
Travel of tailstock quil | mm | 300 (12") | ||
Taper hole of tailstock quil |
| Metric 80 | ||
Main motor power | kw | 30 | ||
Max.weight of workpiece | kg | 16000(optional: 20000) | ||
