CPB- Series CNC Hydraulic Press Brake
- China Port
- T/T
You May Like
-
Upper roller universal 3 rollers plate bending machine
-
Upper roller universal 3 rollers plate rolling machine
-
Hydraulic Press Brake (Bending Machine)
-
(CNC) Hydraulic Press Brake HPB-63/3200, HPB-125/4000, CPB-160/6000
-
3-IN-1 Combina of Shear, Brake & Roll Machine
-
Electric 3-IN-1 Combina of Shear, Brake & Roll Machine
Product Details
| Place of Origin | Henan, China | Brand Name | TIMAC | |
| Model Number | CPB- Series | Condition | New |
Product Description
Specifications
1.CNC Hydraulic Press Brake2.Nominal pressure:40-400ton
3.Length:2200-7000mm
4.Deflection compensation
5.Mechanical stop
CNC Hydraulic Press Brake Machine
Features:
1. Steel-welded construction, vibration to eliminate stress, with high strength and good rigidity.
2. Hydraulic top-strive, steadiness and reliability.
3. Mechanical stop, steel torsion bar to maintain synchronization, high precision.
4. Motorized-adjusting device of backgauge and rams stroke, fine adjusting by handwheel, numerical display.
5. Deflection compensation unit installed on the top die. Manual crowned bottom die holder is adopted for the machine above 250ton, length: 4000mm.
6. Travel limit protection, and full machine guarding with safety interloocker.
Specification | Nominal pressure (KN) | Length of working table (mm) | Depth of throat (mm) | Ram stroke (mm) | Number of stroke (m/min-1) | Motor power (kw) |
CPB-40/2200 | 400 | 2200 | 200 | 100 | 11 | 4 |
CPB-40/2500 | 400 | 2500 | 200 | 100 | 11 | 4 |
CPB-63/2500 | 630 | 2500 | 250 | 100 | 10 | 5.5 |
CPB-63/3200 | 630 | 3200 | 250 | 100 | 10 | 5.5 |
CPB-80/3200 | 800 | 3200 | 320 | 150 | 8 | 7.5 |
CPB-80/4000 | 800 | 4000 | 320 | 150 | 8 | 7.5 |
CPB-100/3200 | 1000 | 3200 | 320 | 150 | 8 | 7.5 |
CPB-100/4000 | 1000 | 4000 | 320 | 150 | 8 | 7.5 |
CPB-125/3200 | 1250 | 3200 | 320 | 150 | 8 | 7.5 |
CPB-125/4000 | 1250 | 4000 | 320 | 150 | 8 | 7.5 |
CPB-160/3200 | 1600 | 3200 | 400 | 180 | 8 | 11 |
CPB-160/4000 | 1600 | 4000 | 400 | 180 | 8 | 11 |
CPB-160/6000 | 1600 | 6000 | 400 | 180 | 7 | 15 |
CPB-200/3200 | 2000 | 3200 | 400 | 200 | 7 | 15 |
CPB-200/4000 | 2000 | 4000 | 400 | 200 | 7 | 15 |
CPB-200/6000 | 2000 | 6000 | 400 | 200 | 7 | 15 |
CPB-250/6000 | 2500 | 6000 | 400 | 250 | 7 | 18.5 |
CPB-300/6000 | 3000 | 6000 | 400 | 250 | 7 | 22 |
CPB-300/7000 | 3000 | 7000 | 400 | 250 | 7 | 22 |
CPB-400/7000 | 4000 | 7000 | 400 | 250 | 7 | 30 |
