Dongfeng DFAC 3 TON Mini Refrigeration Unit 4x2 Food Refrigerator Van Truck for Sale

Main specification

Product model and name

CLW5061XLC3 refrigeration unit

Gross weight(Kg)

6495

Drive type

4x2

Payload(Kg)

2865

Overall dimension(mm)

5995×2020×3000

Curb weight(Kg)

3500

Cab seats

2

Approach/departure angle(°)

19/10

Front/rear hang(mm)

1032/1663

Axle No.

2

Wheelbase(mm)

3300

Axle load(Kg)

2385/4110

Max speed(Km/h)

90

Chassis specification

Chassis model

EQ1060TJ20D3

Manufacturer

Dongfeng Motor Co.,Ltd

Brand name

Dongfeng

Dimension(mm)

5820X1940X2080

Tyre specification

7.00-16

Tyre No.

Steel spring number

8/9+5,6/8+4

Front track base(mm)

1506

Fuel type

Diesel

Rear track base(mm)

1466

Emission standard

Euro 3

Transmission

5 forward gear,1 reverse gear

Cab

Single row, luxurious interiors and seats with power steering. Air condition is optional.

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

CY4102-C3F

Dongfeng Chaoyang Chaochai Power Co.,Ltd

3856

70

Performance

Van body size

4000×1850×1800

Truck body volume(m³)

3(3 TON)

Lowest refrigeration temperature(℃)

-5 to -10 Centigrade

Feature and Application

The refrigerator truck is the closed van truck that is used to transport the frozen or fresh goods. This truck is made up of vehicle chassis, Polyurethane insulation van, refrigeration unit and temperature recorder. It is commonly used to transport the frozen food, dairy products, vegetable and fruit and vaccine medicine etc. For the special requirements of trucks,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots etc. parts can be chosen and installed.
