Foton 3m3 Small garbage truck for sale

FOB Price

US$ 13,000 - 20,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Drive Wheel	4x2
Type	Recycling	Transmission Type	Manual
Emission Standard	Euro 4	Volume	3001 - 6000L
Fuel Type	Diesel	Engine Capacity	2270
Size	560020002400	Gross Vehicle Weight	4155
Place of Origin	Hubei, China	Brand Name	Foton
Model Number	CLW5042ZZZB4	Certification	ISO9001,ccc
After-sales Service Provided	Overseas service center available

Foton 3m3 Small garbage truck for sale

Technical Specifications

Main specifications
Product model,name	CLW5042ZZZB4	Body capacity (m3)	3
Total weight(Kg)	4155	Overall dimension (mm)	4790×1620×2290
Payload (Kg)	1525	Front/rear hang(mm)	1100/1090
Curb weight(Kg)	2500	Wheelbase(mm)	2600, 2850, 3050
cab seats (man)	2	Max speed(Km/h)	90
Approach/departure angle (°)	18/16	Axle load(Kg)	1580/2575
Number of axles	2
Instructions
Self loading garbage trucks is mainly used for the sanitation department of municipal and large factories and mines carry a variety of waste, can also transport dust, sand, stone, soil and other bulk materials, can also transport in the mines or mine ore or coal. The sealed garbage load, hydraulic system, the operating system. Lifting system of oil cylinder ,garbage compartments can hang down, working on the next cycle time 50 s or less.
Chassis specifications
Chassis model	BJ1042V9JB4-X1
Brand name	Foton	Manufacturer	Beiqi Foton Motor Co., Ltd.
Overall dimension(mm)	4820,5010,5320,5620×1690,1720×2080,2190	Tires No.	6+1(spare tire)
Approach/departure angle (°)	18/20	Tire specification	6.00-15
Type of fuel	Diesel	Front track(mm)	1345, 1385, 1415
Drive type	4x2	Rear track(mm)	1240, 1340, 1280
Emission standard	GB3847-2005,GB17691-2005Euro IV
Engine Model	Engine manufacture	Displacement(ml)	Power(Kw)
4B1-82C40	Diesel Engine Co., Ltd., Anhui whole	2270	60
4A1-68C40	Diesel Engine Co., Ltd., Anhui whole	1809	50
4L18CF	Laidong Engine Co., Ltd. Shandong Huayuan	1809	50
YZ4DC1-40	Weichai Power Yangzhou Diesel Engine Co., Ltd.	2160	60

Vehicle Model: Foton 3m3 Small garbage compactor truck

Product Image:
