QLN 304 Farm Wheel Mini Farmtrac Tractors
- Qingdao/Tianjin/Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
QLN 304 Farm Wheel Tractor Mini Farm Tractores
-
QLN 304 Farm Wheel Tractor and Farm Poultry Equipment for Sale
-
QLN 304 Farm Wheel Tractor With Farm Tools and Equipment
-
QLN 304 Farm Wheel Tractor With 3-cylinder Diesel Engine
-
QLN 304 Farm Tractor Types of Four Wheelers
-
QLN 304 Chinese Mini Farm Tracteur
Product Details
| Condition | New | Type | Wheel Tractor | |
| By wheel | 4WD | Usage | Farm Tractor | |
| Drive Type | Gear Drive | Power(W) | 27kw | |
| Certificate | Other, ISO9001:2008 | Brand Name | Qianli Niu | |
| Model Number | QLN | Place of Origin | Henan, China | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
farm wheel mini farmtrac tractors :1.high reliability, low emission
2.good looking surface
3.easy operated
QLN304 farm wheel mini farmtrac tractors
Detailed description
- Farm tractor,low fuel consumption, large traction, advanced chasis and good load-bearing capacity.
- The machine body has a stream line configuration.
- The tractor has a low fuel consumption and a desirable power economic efficiency.
- It has three gearshifts and a wide speed range. Besides, it is flexible in steering and easy to operate
Main devices:
Laidong engine;
Single stage clutch;
PTO speed 720 r/min;
Partial separated hydraulic lifter with positional adjustment;
Clipper-built hood with Foton design;
Gearbox: Forward8+Reverse2;
Front tire:5.5-16(2wd);6.0-16(4wd); Rear tire: 9.5-24;
Hydraulic output with one pair of multi-way valve;
Front ballast 54KG ( 6 pieces) and rear ballast 50KG( 2 pieces);
One year spare parts for free.
Optional devices:
Rops
Sun-shade
Cabin with heater
Cabin with AC
Hydraulic steering
Double speed PTO
Air brake
Pictures
Technical parameters
| Basic configuration | |||
| Model | QLN-300/304 | ||
| Dimensions | Length×Width×Height(mm) | 3200×1500×1880 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1065 | |
| Rear Wheel(mm) | 1250-1200 | ||
| Min.Ground Clearance(mm) | 380(4WD) 330(2WD) | ||
| Dry Mass | Complete tractor weight(KG) | 1240(4WD) 1200(2WD) | |
| Engine | Trade Mark or Brand | LAIDONG | |
| Engine Model | Vertical Water Cooled 3-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 3 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 22.1KW | ||
| Fuel Tank | Volume(L) | 41.3 | |
| Transmission System | Clutch | Single,Dry,Single Stage Type | |
| Gear Box | F8+R2 | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Mechanical,dry type | ||
| Running System | Tyre Model | F/R(2WD) | 5.5—16/9.5—24 |
| F/R(4WD) | 6.0—16/9.5—24 | ||
| Steering System | Mechanical for 2wd tractor and Hydraulic steering for 4wd tractor | ||
| Working Device | Hydraulic System Type | Partial seperated lifter | |
| Linkage Type | I Rear Mount 3-point Linkage | ||
| PTO(Standard) | Φ35×6 | ||
| PTO Speed(r/min) | 720 | ||
| Drawbar Type | Fixed Drawbar | ||
| Optional configuration | |||
| Cab with Heater | Cab with AC | ROPS | Sunvisor |
| Adjustable Comfort Seat | Multiple Unit Valve | Hydraulic steering for 2WD | Dual-stage clutch |
| Double PTO Speed(r/min): 540/720 540/1000 720/1000 | |||
| Bob-weight | Frontballest | 6×10=60kg 10kg/pcs | |
| Rearballast | 2×25=50kg 25kg/pcs | ||
Main types
QLN has over 70 types tractors mainly in 6 series.
1. 35 series 250-354 (from 25hp-35hp 2/4wd)
2. 40 series 400-554B (from 40hp-55hp 2/4wd)
3. 50 series 550-654 (from 55hp-65hp 2/4wd)
4. 80B series 700-854B (from 70hp -85hp 2/4wd)
5. 80A series 800-1004 (from 80hp-100hp 2/4wd)
6. 100 series 1104-1304 (from 110hp-130hp 4wd)
Matched implements
Our clients
Our honors
Our company
please feel free to contact us, we will try our best to meet your needs !!!
looking forward to cooperating with you !!!
