LSS1901 Single Steel Road Roller Compactor
- Qingdao/Shanghai/Tianjin
- T/T
You May Like
Product Details
| Condition | New | Type | Single Drum Roller | |
| Static Linear Pressure | 437 N/cm | Travel Speed | 10.5 Km/h | |
| Grade Ability | 35 % | Place of Origin | Henan, China | |
| Brand Name | YTO | Model Number | LSS1901 | |
| Power(W) | 132 Kw | Dimension(L*W*H) | 6600*2300*3000 | |
| Weight | 19000 Kgs | Certification | ISO9001 Certification | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
LSS1901 Single Steel Road Roller Compactor
Applications:
Heavy duty vibratory rollers are suitable for compaction of non-cohesive materials such as gravel, crushed stone, sand-macadam mixture, sandy soil and rock filling etc. on base course, sub-base and embankment fill construction, which are ideal equipment for high-class highway, railway, airport, harbors, dams and large-scale industrial ground.
Main Features:
- GUO II emission standard engine. Engine cooling air-path structure and large capacity of fuel tank.
- One handle controlled pneumatic shift control mechanism. Parking brake is controlled by cutting air, which is safe and reliable.
- Dual amplitude setting of vibration;New types of vibration device and drum travel bearing structure. Heavy -duty gearbox. Driving axle with.
- Joint-moving mechanism of the clutch pedal with engine throttle. Adjustable instrument desk with liquid crystal instrument panel.
- MP3 supported music system with USB and SD interface. Modernized style overall appearance. Driver’s cabin with T type angular glasses.
Technical Parameters:
Model |
| LSS1901-2 |
Operating mass | kg | 19000 |
Static linear load | N/cm | 437 |
Vibration amplitude | mm | 2.0/1.0 |
Vibration frequency | Hz | 28 |
Centrifugal force | kN | 340/200 |
Max travel speed | km/h | 10.5 |
Gradeability | % | 35 |
Turning radius | mm | 7500 |
Drum width | mm | 2130 |
Drum diameter | mm | 1600 |
Wheelbase | mm | 3430 |
Ground clearance | mm | 445 |
Diesel model |
| SC8D180 |
Diesel power | kW | 132 |
Overall dimensions | mm | 6600×2300×3000 |
