Popular Selling 325KG Walk Behind Road Roller RS600 Single Drum Steel Roller
- Shanghai Qingdao Tianjin Port
- T/T Credit Card
You May Like
Product Details
Condition | New | Type | Single Drum Roller | |
Static Linear Pressure | 40N/cm | Travel Speed | 0~3.0 km/h | |
Grade Ability | 30% | Place of Origin | Jiangsu, China | |
Brand Name | XCMG | Model Number | RS600 | |
Power(W) | 5.5HP | Dimension(L*W*H) | 1100x1000x1200mm | |
Weight | 200 kg | Certification | ISO, CE | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Chinese Vibratory Road Roller Single Drum Road Roller
200KG Mini Road Roller, 325KG Mini Road Roller
Popular Selling 200KG/320KG Walk Behind Road Roller RS450/RS600
Application:
Used for compaction of asphalt surface, compaction of gravel, sand and other projects. The walk-behind vibratory rollers are small-size vibratory rollers, applied to mending and maintaining various roads, expressway shoulder, roadside walk, parking area, sports ground and garden lawn. They are especially suited for compaction of narrow areas as pipeline channel and drainage trench etc
Features:
1. Small operation radius, can work in narrow area;
2. Famous HONDA gasoline engine, superior performance, easy to start.
3. International famous brand hydraulic drive mechanism, stepless speed changing, easy change of direction, long life working;
4. Handrails using plane gear adjusting mechanism, flexible, can adapt to different height workers to operate;
5. NSK Bearings by internationally renowned, MITSUBOSHI (Samsung) belt, to ensure that the work performance of the machine;
6. Surface spray, beautiful appearance, rust resistant.
7. Large capability hydraulic fuel tank;
8. Seamless steel wheel by boring machine processing, high degree of accuracy, high hardness;
9. Scraper blade to prevent the aggregation of soil and asphalt, to make road surface more smooth.
10. Offical designated using by Sinohydro Corporation Limited, China Railway Construction Corporation, Expressway Group, Energy China Group, Oceanwide Real Estate Group, and etc. Because of its proved high quality. It is also widely exported to a lot of countries.
Model | RS450 | RS600 |
Walking Parameters |
|
|
Walk Speed | 0-3km/h (F/R) | 0-3km/h (F/R) |
Max. Grade-ability | 30% | 30% |
Compaction Parameters |
|
|
Static Linear Load | 40N/cm | 40N/cm |
Compacting Width | 0.6mm | 0.6mm |
Vibration Frequency | 70Hz | 70Hz |
Centrifugal force | 15kN | 15kN |
Drive Mode |
|
|
Drive | Hydraulic Type | Hydraulic Type |
Vibration | Automatic Clutch | Automatic Clutch |
Engine |
|
|
Model | HONDA GX160 | HONDA GX160 / Changfa CF170F |
Type | Gasoline (water cooling, four stroke, OHV, single cylinder) | Gasoline/Diesel (water cooling, four stroke, OHV, single cylinder) |
Rated Power | 5.5HP | 5.5HP/5.0HP |
Hydraulic Oil Tank | 16L | 19L |
Water Tank | Null | 17L |
Dimension |
|
|
Steel Drum Width | 450mm | 600mm |
Steel Drum Diameter | 425mm | 425mm |
Packing Size | 750x750x900mm | 1100x1000x1200mm |
Weight |
|
|
Net Weight | 200kg | 325kg |
Starting Mode | Manual Operation | Manual Operation / Electric Starting |
Product Pictures
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
