Home > Products > Lifting Machinery > ZOOMLION Crawler Crane 55 Tons ZCC550H
ZOOMLION Crawler Crane 55 Tons ZCC550H
- 100 Unit / Units per Month
- Shanghai Qingdao Tianjin
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Condition | New | Application | Construction | |
| Rated Loading Capacity | 55 ton | Rated Lifting Moment | 1062.4T.m | |
| Max. Lifting Load | 55ton | Max. Lifting Height | 67m | |
| Place of Origin | Hunan, China | Brand Name | ZOOMLION | |
| Model Number | ZCC550H | Certification | ISO,CE | |
| Warranty | 1 year warranty | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
ZOOMLION Mobile Crane 55T
ZOOMLION Crawler Crane 55 Tons ZCC550H
Main Features:
Model: ZOOMLION ZCC550H
Transporting state(mm)
Boom length of long jib(m) 13~52m
Boom length of long vice jib(m) 6~15m
Enging brand/enging power(kw) WP6G190E26/140kW
Whole machine weight (t) 51t
Max hosting capacity(t) 55t
Technical Specification
Type | Ser. No. | Item | Unit | Value |
Boom section configuration | 1 | Maximum lifting weight ×radius | t×m | 55×3.7 |
2 | Maximum lifting weight of fixed jib | t | 5.5 | |
3 | Length of main boom | m | 13~52 | |
4 | Length of fixed Jib | m | 6~15 | |
5 | Longest main boom + fixed jib | m | 43+15 | |
6 | Luffing angle | ° | 30~80 | |
7 | Fixed jib installation angle | ° | 10,30 | |
Mechanism velocity | 8 | Speed of rope on the drum of main winch | m/min | 120/100 |
9 | Speed of rope on the drum of auxiliary winch | m/min | 120 | |
10 | Speed of rope on the drum of derricking winch | m/min | 54 | |
11 | Swing speed | rpm | 0~2.1 | |
12 | Travelling speed | km/h | 0~1.6 | |
| 13 | Model | / | WP6G190E26 |
Engine | 14 | Type | / | Inline 6-cylinder intercooled turbocharged diesel engine |
15 | Rated power / speed | kW/rpm | 140/1900 | |
16 | Maximum output torque / speed | Nm/rpm | 830/1300 | |
17 | Displacement | L | 6.23 | |
18 | Emission standard | / | WP6G190E26 | |
Others | 19 | Gradeability | % | 30 |
20 | Pressure to the ground | MPa | 0.069 | |
21 | Dead weight with basic boom attached | t | 51 | |
22 | Total weight of complete configuration | t | 57 | |
23 | Counterweight | t | 17.5 | |
24 | Maximum transport weight of single part | t | 32 | |
25 | Outline dimension length ×width ×height | mm | 12800×4600(3300)×3120 | |
26 | Crawler gauge ×crawler length × crawler width | mm | 2540×5000×760 | |
3840×5000×760 |
