Small Bulldozer SHANTUI Bulldozer SD13 and spare parts
- Shanghai Port
- T/T Credit Card
You May Like
-
130 HP Series bulldozers SD13
-
2015 New CS915 Artiuclated Mini Wheel Loader with CE, Joystick, Quick-action couplings
-
Static Hydrulic Drive 1.2 ton Mini Wheel Loader CS912 with Quick Hitch
-
China Mini Loaders Manufacturer ZL10, ZL12, ZL15, ZL18, ZL20, ZL30
-
CAISE Mini Wheel Loader CS912
-
1T loader CS912 Mini Loader for the European market
Product Details
| Place of Origin | Shandong, China | Brand Name | SHANTUI | |
| Model Number | SD13 | Condition | New | |
| Moving Type | Crawler Bulldozer | Machine Weight | 15.2t | |
| Dimension(Long * Breadth * High) | 4492*3185*2950mm | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Small Bulldozer SHANTUI Bulldozer SD13 and spare parts
SHANTUI SD13, SHANTUI SD16, SHANTUI SD22, SHANTUI SD23, SHANTUI SD32
Best Quality Chinese Bulldozer 130HP SHANTUI Bulldozer SD13 for Sale
Chinese Bulldozers SHANTUI construction machine sd13
Rated Power: 95.5kW/1900rpm
Engine Shangchai SC8D143G2B1 (D6114ZG4B)
Operating Weight: 15.2t
Dozer Type: Straight/Angle
Type | SSHANGCHAI D6114ZG4B (water cooled, in-line, direct injection and turbo charge) |
Rated revolution | 1900rpm |
Rated power | 95.5kw |
Cylinder number-bore x stroke | 6-114 x 135 |
Piston displacement | 8.27L |
Rated fuel consumption | <=228g/kW.h |
Max. Torque | 674.m/1300rpm |
Under Carriage System
Type | Swing type of sprayed beam, suspended structure of equalizer bar |
Carry rollers | 2 each side |
Track rollers | 6 each side |
Track type | Single teeth. Dry type |
Width of track shoes | 460mm |
Pitch | 190mm |
Hydraulic System
Max. Pressure | 14MPa |
Pump type | Gear pump |
Discharge | 180L/min lated revelation |
Working cylinder x number | 90mm x2 |
Power Transmitting System
Torque converter | 3-element, 1 stage, 1 phase |
Transmission | Forced connected, planetary gear |
Main drive | Spiral bevel gear, splash lubrication |
Steering clutch | Wet, Multi-disc, spring loaded, hydraulic helping operation, mechanical separating, linking steering brake |
Steering brake | Wet, floating, band type foot stepping brake with hydraulic helping |
Final drive | 2-stage speed reduction of spur gear, splash lubrication |
Blade
Blade | Straight-tilt | Angle |
Min. Ground clearance(mm) | 320 | 320 |
Operating weight(kg) | 14000 | 14500 |
Ground pressure(MPa) | 0.064 | 0.064 |
Gradeability | 30 | 30 |
Track gauge(mm) | 1880 | 1880 |
Dozing capacity(m3) | 3.7 | 3.4 |
Blade height(mm) | 1090 | 915 |
Blade width(mm) | 3185 | 3745 |
Max. Drop below ground(mm) | 590 | 590 |
Max. Tilt adjustment(mm) | 400 | 400 |
Travel Speed
Gear | 1st | 2nd | 3rd |
Foward(km/h) | 3.2 | 5.9 | 9.8 |
Reverse(km/h) | 3.9 | 7.1 | 11.9 |
