WHEELED TRACTOR BOMR304
- QINGDAO
You May Like
Product Details
| Use | Tractors | Place of Origin | Henan, China | |
| Brand Name | BOMR | Model Number | BOMR304 |
Product Description
Specifications
1. 8F+2R shift2. Italy fiat chassis
3. Increase 30% efficiency
4. save 25% of fuel
The characteristics of tractor from 25hp to 35hp
- Semi-separation hydraulic lifters are using reliable. Lifter cylinder bore is 80mm (other companies are 75mm).
- Final drive transmission use planetary reducer structure. Large transmission ratio, load bearing equality, stably transmission, little noise and long life using. ( the common size)
- The ground clearance of High ground clearance tractors (B280H/ B 300H/B350H) is 150mm higher and better through performance than the common ones.
- When you shifting or slowing down, the gear pump in the front is not affect the agricultural implements. It is satisfied with customer using tractor in the farm.
- Wet disc brake is using stably ,reliably, and long time
- The speed is 10%-27% higher than other same type tractor. It is high efficiency and saving fuel in the transport.
- The tractor has pin-type differential locks; this can avoid single side slipping effectively when climbing the mountain or bridge slope. It drives quickly and strongly.
- Air filter is 200-350mm taller than other same products. It can reduce engine troubles and keep sir clean when air through in.
- The tractor’s lamps are more than other same products. It is more bright and safe when driving in the night.
10. The tractor’s hood has spring open structure. It’s convenient when opening hood.
11. Strainer is fit in the front of water tank; it can avoid hays and sundries to block up water tank. Strainer is convenient for loading or unloading and cleaning.
12. Front and rear wheel tread are adjustable. So our tractors are suitable for use in different farmland.
.
| The main specification of bomr 30hp to 35hp tractor | |||||
| Tractor Model | 300 | 304 | 350 | 354 | |
| General Specification | Driver Type | 4×2 | 4×4 | 4×2 | 4×4 |
| Length*width*Height(mm) | 3545*1488*1922 | 3545*1488*1923 | 3545*1488*1924 | 3545*1488*1925 | |
| Traction force(KN) | 6.2 | 7.5 | 7.9 | 9.48 | |
| Steering | Machanical | hydraulic | Machanical | hydraulic | |
| Wheel base(mm) | 1634 | 1675 | 1755 | 1799 | |
| Front wheel tread(mm) | 1172-1472 | 1200 | 1172-1472 | 1200 | |
| Rear wheel tread(mm) | 1148-1448 | 1148-1448 | 1148-1448 | 1148-1448 | |
| P.T.O.Max.Power(Kw) | 18.8 | 18.8 | 21.8 | 21.8 | |
| Ground clearance(mm) | 320 | 260 | 360 | 280 | |
| Engine | Type | SL2105ABT2 | SL2105ABT2 | SL3100ABT2 | SL3100ABT2 |
| Bore×Stroke(mm) | 105*117 | 105*117 | 100*117 | 100*117 | |
| Rated revolution (r/min) | 2300 | 2300 | 2300 | 2300 | |
| Max.torque(n.m) | ≥114.2 | ≥114.2 | ≥131.8 | ≥131.8 | |
| Speed of Max.torque r.p.m. | ≤1725 | ≤1725 | ≤1725 | ≤1725 | |
| Transmission | Clutch | Single-stage clutch | |||
| Gear box | 8F+2R | ||||
| Working device | Lifter tilling depth control | Power,bit-conditioning | |||
| Max.lifting capacity( KN ) | 5 | 5 | 5.8 | 5.8 | |
| Suspension type | Class 1 3-Point hitch | ||||
| Speed of P.T.O.(r/min) | stardard:540/720;optional:540/1000,720/1000 | ||||
| Notice:All above parameters are subject to change without notice because of rapid development of products. | |||||
Packing :One 40" high container can load 8 units Loading in container in nude
Shipping:15 to 25 days
