110hp Farm Use Cheap China Tractor
- Qingdao
- T/T D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Wheel Tractor | |
| By wheel | 4WD | Usage | Farm Tractor | |
| Drive Type | Other, wheel drive | Power(W) | 80.9KW | |
| Certificate | Other, ISO9001:2008 | Brand Name | BOMR | |
| Model Number | BOMR1104 | Place of Origin | Henan, China | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
110hp Farm use cheap china tractor
110hp YTO engine farm tractors
110hp Farm use cheap china tractor 110hp YTO engine farm tractors
1.Domestic famous engines, strong driving force, low fuel consumption, high economic benefits
2.12F+4R sliding sleeve shift, reasonable speed configuration and good adaptability
3.Flat floor, hanging pedal, right side control, humanity design, comfortable operation and easy adjustment
4.540/1000r/min double speed PTO, wide range of matched implements
5.Adjustable forced lift, the better effects of rotary tillage and plough.
6.150L bigger fuel tank, longer working time.
7.Quick change and height adjustable traction, more convenient disassembly
8.The car design uses 17 patents, leading to the high-end technology.
9.Optional multi-valve hydraulic output mechanism satisfies the diversified machinery operation.
10.Four planet gear differential mechanism, steady transmission, high reliability.
11.Optional air condition and heater cabin
12.Optional pneumatic braking device can carry out many farm and transport works.
13.Optional pneumatic braking device is adapted to multi farm and transport work.
Technical Parameters
| Technical Parameters | ||||||
| Model | 754 | 804 | 904 | 1004 | 1104 | |
| General Parameter | Drive Type | 4WD | ||||
| Dimensions LxWxH (mm) | 4520×2135×2750 | 4520×2135×2750 | 4520×2170×2850 | 4520×2170×2850 | 4650×2150×3040 | |
| Front Wheel Track (mm) | 1569-2005 | 1630-1960 | ||||
| Rear Wheel Track (mm) | 1500-2100 | 1520-2120 | ||||
| Wheel Base(mm) | 2325mm | |||||
| Ground Clearance (mm) | 370 mm | 430mm | 440mm | |||
| Rated Traction Force (kN) | 16.5 kn | 17.6 kn | 19.8kn | 24kn | 26kn | |
| Min. use weight (Kg) | 3540kg | 3675kg | 3920kg | |||
| Min. Turning Radius (m) | ≤5.3 m | |||||
| Speed range | 1.55-27.99Km/H | 1.57-28.35Km/H | 1.6-33.77Km/H | |||
| Diesel Engine | Model | YT4B4-23 | YT4B4-23 | LR4M5-23 | LR4V5-23 | LR6B3-23 |
| Type | 4 Cylinder , 4-Stoke Cycle Water Cooled,Vertical aligned | 6 Cylinder , 4-Stoke Cycle Water Cooled, Vertical aligned | ||||
| Rated Power (kw/hp) | 55.1kw75HP | 58.8kw/80HP | 66.1kw/90HP | 73.5kw/100HP | 80.8kw/110HP | |
| Rated Speed (rpm) | 2300 | 2300 | 2300 | 2300 | 2300 | |
| Bore x Stroke (mm) | 108×130 | 108×130 | 112×135 | 115x135 | 108x125 | |
Rated fuel consumptio rate | ≤242 (g/Kw.h) | |||||
| Transmission System | Gear Box | Combined 12F+4R 12 forward gears , 4 reverse gears,creeper shift (24F+8R) or shuttle shift (12F+12R) for option | ||||
| Rear axle--Central transmission | Spiral Bevel gear | |||||
| Rear axle--Differential | 4 planet bevel gears | |||||
| Rear axle--Differentila Lock | Locking pin type | |||||
| Rear axle--Final Transmission | Single planet bevel gear,outer mounted at both sides of rear axle | |||||
| Front drive --Transmission shaft | Central Transmission shaft | |||||
| Front drive -Central transmission | Spiral Bevel gear | |||||
| Front drive -Front diffenential | 2 planet bevel gears | |||||
| Front drive-Final Transmission | Single-planet gearsing | |||||
| Clutch | dry style double action | |||||
Traveling Mechanism | Front Tyre | 11.2-24 | 11.2-28 | 13.6-24 | ||
| Rear Tyre | 16.9-30 | 13.6-38 | 16.9-34 | |||
| Steering Gear | Hydraulic Steering | |||||
| Brake | Oil Immersed Multiplate Disc | |||||
Working Device | Oil fuel tank | 145 L | ||||
Lifting Capacity (at 610 mmBehind LiftPoint (N)) | ≥13.3kN | ≥14.2kN | ≥15.9kN | ≥17.6kN | ≥19.5kN | |
| Hydraulic System: | 3-Point Suspension | |||||
P.T.O shaft : Rotating Speed (rpm) | 540/1000 | |||||
| Spline Size | 6-Ø35 Rectangular Spline | |||||
110hp Farm use cheap china tractor
Tractor detail pictures
110hp Farm use cheap china tractor
PACKING IN NUDE ,ONE 40HQ LOAD 2 SETS
110hp Farm use cheap china tractor
Our services
Warranty:
12 months is from the date of commissioning, or at the latest, 12 months from delivery.
After-sale service:
1. When loading tractor, we will delivery some normal spare part and tools as free together
with tractor, including tool box.
2. When the tractor have problem in warranty, pls take pictures as evidence. After make sure
(the problem must not be caused by man made destructive factors), we will send out the spare parts as free at once. But freight is paid
by customer.
3. After the warranty, the spare parts cost is paid by customer.
Our tractor in Canton fair:
Company certification:
Please do not hesitate to contact us , if you are interested in our products.
we will try our best to meet your needs !!!
110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor 110hp Farm use cheap china tractor
