Home > Products > Logistics Machinery > 3T Gasoline Forklift with 2 stage 3m Mast
3T Gasoline Forklift with 2 stage 3m Mast
- 1000 Unit / Units per Month
- Shanghai Tianjin Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Semi AC Motor 2 Ton HUAHE Electric Forklift Truck CPD20 HEF20
-
General industrial equipment hot sale new 3.5T gasoline forklift price
-
2.5 Ton YTO Hydraulic Forklift Truck CPCD25
-
Cheap Price Electric forklift truck CPCD30
-
YTO Chinese 7 ton Diesel forklift truck specification CPCD70
-
YTO Chinese 7 ton Diesel forklift specification CPCD70
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | HUAHE | Model Number | HH30Z-W21-G | |
| Type | Powered Pallet Truck | Power Souce | Gasoline Engine | |
| Rated Loading Capacity | 3500kg | Max. Lifting Height | 6000mm | |
| Min. Lifting Height | 3000mm | Fork Length | 1070mm | |
| Fork Width | 125mm | Overall Dimensions | 2680x1225x2180mm | |
| Certification | CE/ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
3T Gasoline Forklift with 2 stage 3m Mast
Engine: Orgine Japanese NISSAN K25(EU III)
Mast: 3 stage Full Free Mast( 4.5-6M)
Tires: Pneumatic Tire-Cheng Shin Tire
Generals | Model | Unit | HH30 | HH30Z | |
Power type |
| Diesel | |||
Rated capacity | Kg | 3000 | |||
Load center | mm | 500 | |||
Dimensions | Lift height | mm | 3000 | ||
Free lift height | mm | 130 | |||
Fork size (L×W×T) | mm | 1070×125×45 | |||
Mast inclination F/R | Deg | 6°/12° | |||
Front overhang | mm | 490 | |||
Overall Dimensions | Length to face of fork | mm | 2680 | ||
Overall width | mm | 1225 | |||
Mast lowered height | mm | 2200 | |||
Overhead guard height | mm | 2120 | |||
Turning radius | mm | 2460 | |||
Min. right angle aisle width | mm | 2105 | |||
Performance | Travel speed | Unload I/II | Km/h | 9/20 | |
Full load I/II | Km/h | 8.8/18.5 | |||
Lift speed | mm/s | 480 | |||
Max. grade ability | % | 20 | |||
Max. drawbar pull | Kn | 13 | |||
Self weight | Kg | 4400 | |||
Wheels & Tires | Tires | Front |
| 28×9-15-12PR | |
Rear |
| 6.50-10-10PR | |||
Tread | Front Q | mm | 1000 | ||
Rear S | mm | 970 | |||
Wheelbase | mm | 1700 | |||
Min. ground clearance (unload/full load) | Mast | mm | 152/132 | ||
Frame | mm | 158/138 | |||
Drive units & Control | Battery | V/Ah | 12/90 | ||
Engine | Model |
| Nissan K25 | ||
Rated output | Kw/rpm | 44/2500 | |||
Rated torque | N.m/rpm | 186/1600 | |||
Displacement | cc | 2472 | |||
Transmission | Type |
| Mechancial/Hydraulic | ||
Shift Fwd/Rwd |
| 1/1 Power shift | |||
Operating pressure | Mpa | 17.5 | |||
