Flat bed trailer CIMC 40FT 20FT Skeletal truck trailer transport
- Qingdao Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Type | Semi-Trailer | Material | Steel | |
| Certification | CE | Size | 12.4*2.5*1.55 METERS | |
| OEM No. | N/A | Max Payload | 40T | |
| Place of Origin | Shandong, China | Brand Name | HUAYU | |
| Model Number | N/A |
Product Description
Flat bed trailer CIMC 40FT 20FT Skeletal truck trailer transport
Telescopic EURIC Lifting Oil Cylinder with multi-sleeves is equipped with the tipper lorry:
1. It is a cooperative production between our company and Finland NUMMI;
2. It is of high quality and reliable performance as well as competitive price; it is widely used in dump trucks like side-tipping dump cars as well as compression equipments;
3. Simple structure, high lifting moment, low hydraulic cylinder pressure and stable lifting operation;
Components of Front Tipping Dump Truck (Tipper Lorry or Production Truck):
1. Components of tip trucks: Hydraulic Lifting System, carriage, sub frame and accessories;
2. Hydraulic lifting system contains oil pump, hydraulic cylinder, operating equipments;
inhibiting device, oil tank and pipe line and other related components;
3. Carriage includes front board, back board, floor and opening and closing mechanism etc;
4. Accessories includes safety pole, limiting plate and limiting cable etc.
Working Principle of Front Tipping Dump Truck (Tipper Lorry or Production Truck):
Engine power is output by Transmission and PTO; then the power goes through oil pump drive spindle and then drive the oil pump; then hydraulic oil goes through distributing valve and finally goes into hydraulic cylinder. The carriage ultimately dump or tilting goods or materials based on the power of hydraulic cylinder’s stretching motion.
Tare weight | 15000kg | Payload | 25000kg | |||||||||
Overall length | 10400mm | Overall width | 2280mm | Overall height | 2000mm | |||||||
Chassis | Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-AAC processes. Top plate 16mm .bottom plate 16mm .middle plate 6mm .height:520mm .width 146mm | |||||||||||
Axle | Number | 3 | Brand | BPW | Capacity | 12 T | ||||||
Suspension | Mechanical suspension | |||||||||||
Leaf spring | Leaf spring 12 pcs | |||||||||||
Floor | 8mm plate .side wall 6 mm with crane | |||||||||||
Tire | 11R22.5 double star 13 pcs | |||||||||||
Wheel rim | 8.25-22.5 13pcs | |||||||||||
Kingpin | JOST 3.5’’ bolt-in king pin | |||||||||||
Landing gear | JOST A400 two-speed, manual operating ,heavy duty landing gear | |||||||||||
Cylinder | HYVA 214-5-9030 | |||||||||||
Vehicular applications | Sand and pebble and mineral transport | |||||||||||
Drawing | Including | |||||||||||
Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber; 40L air tanks | |||||||||||
Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint | |||||||||||
Accessories | One standard tool box | |||||||||||
