Home > Products > Spare Parts > Small Mini Electric Manual Hand Stacker Forklift
Small Mini Electric Manual Hand Stacker Forklift
- Shanghai Port Tianjin Port Qingdao Port
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | YTO | Model Number | CPD20 | |
| Type | Powered Pallet Truck | Power Souce | DC Motor | |
| Rated Loading Capacity | 2000kg | Max. Lifting Height | 6000mm | |
| Min. Lifting Height | 3000mm | Fork Length | 1070mm | |
| Fork Width | 125mm | Overall Dimensions | 2380mm*1150mm*2150mm | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
nude package
Product Description
small mini electric manual hand stacker forklift
Speciality parameter  | Model | CPD20 | ||||
| Power type | Battery | |||||
| Rated capacity | kg | 2000 | ||||
| Load center | d | mm | 500 | |||
| Lift height | h2 | mm | 3000 | |||
| Mast tilt angle (forward/backward) | α/β | Deg | 6/12 | |||
| Front overhang | L3 | mm | 483 | |||
| Wheel-base | L4 | mm | 1500 | |||
| Tread(front/rear) | b4/b5 | mm | 970/950 | |||
| Performance parameter | Travel brake | Hydraulic-Foot pedal | ||||
| Parking brake | Mechanical-Hand lever | |||||
| Lift speed(with/without load) | mm/s | 260/400 | ||||
| Lower speed (with/without load) | mm/s | (with load)300 | ||||
| Travel speed (with/without load) | km/h | 11/12 | ||||
| Max. gradeability (with load) | % | 1 | ||||
| Power, transmission and others | motor | Driving motor | Model | XQ-6.3-1T | ||
| Rated power | kw | 6.3 | ||||
| Rated rotation | r/min | 1200 | ||||
| Working motor | Model | XQD-8.6-C | ||||
| Rated power | kw | 8.6 | ||||
| Rated rotation | r/min | 1550 | ||||
| Controller | Manufacturer | GE | ||||
| Type | MOSFET | |||||
| Battery | Voltage | V | 48 | |||
| Capacity | Ah | 630 | ||||
| Size(L×W×H) | mm | 820×1065×520 | ||||
| Gearbox | Transmission type | Mechanical | ||||
| Tire | type | Pneumatic tyre | ||||
| Model | Front | 7.00-12-12PR | ||||
| Rear | 18×7-8-14PR | |||||
