Plain weave stainless steel woven wire mesh

Plain weave stainless steel woven wire mesh

Ultra fine stainless steel wire mesh

Stainless steel wire mesh

SS Wire Cloth
Material:302,304,304L,316,316L,321
Packaging: paper tube, waterproof paper, hubble film, wooden case

Material: 304,304L,316,316L
Wire diameter: 0.025mm-0.053mm
Weaving method: plain weave, twill weave

1. Plain Weave: also called tabby weave, linen weav or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple criss-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.
2. Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.

Characteristics:wear-resisting, heat-resisting,acid-resisting,corrosion resisting

304 Stainless Steel Wire Cloth is the most common stainless alloy used in wire weaving. Excellent corrosion properties and can withstand temperatures of 1100 Degrees F.

304L Stainless Steel Wire Cloth has similar properties as 304ss but lower carbon content to permit better welding.

316 Stainless Steel Wire Cloth has similar properties to 304ss but is stabilized by the addition of Molybdenum for increased resistance to chemical corrosion.

316L Stainless Steel Wire Cloth has similar properties as 316ss but lower carbon content to permit better welding.

Usage: extensively used in mining, chemical industry, food industry and pharmaceutical industry
Packaging:in waterproof paper, pvc bag, moist proof paper,wooden case,pallet.
