2014 NEW 3 in 1 Car FM Radio Transmitter Charger Holder Handsfree Kit For iPhone5 Touch5

Specifications

2014 NEW 3 in 1 Car FM Radio Transmitter Charger

Holder Handsfree Kit For iPhone5 Touch5

Features:

Hi-Fi FM stereo transmitter allows you to fully enjoy your music.
Supports iPhone hands-free feature through your car speaker system.
Suitable for all iPhone, all iPod and MP3 player
Support USB charging and FM transmitter simultaneously.
Support  mobile phone and GPS charging with 5V/1A output USB socket.
LCD frequency display with orange backlight for easy to read display.
Adjustable arch design.
High quality silicone fixer prevents the i-Kit from rotating
The fiexible goose-pipe makes it convenient to find the best position for your device. It is compatible in the worldwide. Goose-pipe with rotation prevention design keeps your devices steady & firm in its position
Operating Guide
Preparation For Usage
Insert the cigarette power adapter into the car’s cigarette lighter. Now adjust the ALLKITII to a suitable position and then put your device onto the cradle.

Using With iPhone(8 pin Connector)
Place the iPhone on the ALLKITII cradle, and adjust the cradle to fit the iPhone securely.

Connect the iPhone to ALLKITII 8pin connector. Now use the 3.5 stereo cable to connect the iPhone and ALLKITII for audio.

NOTE:
This will also charge the iPhone, and also allows you to  listen to music of your iPhone and hands-free calling
Place the iPod on the ALLKITII cradle, and adjust the cradle to hold the iPod securely.
Connect the iPod to ALLKITII 8pin connector. Now use the 3.5 stereo cable to connect the i-pod and ALLKITII for audio.
Place the device on the ALLKITII cradle, and adjust the cradle to hold the device securely.
Use the 3.5 stereo cable to connect your device and ALLKITII for audio.

NOTE:
Please make sure your device has audio playback
USB Charger
Connect your USB device to ALLKITII USB port to charge your device.
NOTE:
Please check if your USB device supports the standard
Specifications
NOTE:
All specifications are subject to change without notice.
Product
Model: ALLKITII

Frequency:

Band: FM frequency
Quality: Hi—Fi stereo
Range: 88.1~107.9MHZ
Interval: 0.1 MHZ
Stability: ±l0ppm (-1°C-+55°C)
Clutter & Harmonic: ≤-60dB
Effective Range: ≤5m
Power
Working Voltage: DC l2V
USB Output Voltage: DC 5V 1A max
Audio
Stereo Separation: 40dB
Frequency Response: 20Hz~16KHz
Audio Distortion: ≤0.1% (F=75KHz, f=l KHz)
SNR: ≥45d B(1 KHz l00%)
Physical
Dimension: 110 x 65.5 x 40mm
Weight:191g
Input Terminate
Charger:8 Pin connector
Audio in: 3.5 stereo
Notes
Please avoid using local radio signal frequencies to ensure better sound quality.
Please adjust the volume on the device or the car stereo to ensure proper volume levels.
Please carefully check the electricity capacity of your equipment when using as a USB
charger
Warning
Warranty will be voided if modifications or alterations have been made to the device.

Device contains removable parts please monitor when around children

Rule Statement
The ALLKITII is a radio transmitter device, in accordance with part 15 of FCC rules, the product meets the requirements of Class B digital products restrictions by the specific circumstances of the impact of the following two conditions:

This device will not cause any harmful interference.

The device must be able to accept the receipt of the interference, including the possibility of operator error caused the interference.

Maintenance Attention To The Issues
Please use a clean soft cloth to clean this device.
For prolonged use of the device, device should be disconnected from vehicle cigarette lighter port.
