Stainless Steel Zhejiang Gear Type Rotary Lobe Molasses Pumps
- shanghai/ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
China Suppliers Steel Food Grade G Type Screw Single Sauce Pump
-
China Suppliers Stainless Steel Helical Rotor Twin Screw Paste Pump
-
Steel G Type Screw Food Industrial Helical Rotor Pump for Sale
-
Sanitary Stainless Steel Rotor Stator Pumps/lobe Pump
-
Food Class Stainless Steel Chocolate Rotor Pump
-
Stainless Steel Hygienic Lobe Molasses Pumps(rotor Pump)
Product Details
| Place of Origin | Zhejiang, China | Brand Name | BLS | |
| Model Number | BLS | Theory | Other, Gear type Rotary Lobe Molasses Pumps | |
| Structure | Gear Pump | Usage | Other, Gear type Rotary Lobe Molasses Pumps | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, electric | Pressure | High Pressure | |
| Application | Other, Gear type Rotary Lobe Molasses Pumps, Gear type Rotary Lobe Molasses Pumps |
Product Description
Basic Information:
Stainless Steel Zhejiang Gear type Rotary Lobe Molasses Pumps
Abstract
Stainless steel lobe pumps (also called as colloid pumps, rotor pumps, threeleaf pumps and etc.), are widely used on beer, food, dairy, beverage, chemical and medical industry and so on. For the special shape of the rotor and the high precision, we make rotor curve program composition by C Language and then input in machining centre to process, which confirms the high precision of the key parts and the strict requirement.
Characteristic
Lobe pump belongs to positive displacement pump, flow can be controlled accurately and can change to variable pump conveniently.
The rotation speed of lobe pump is very low, normally between 100rpm and 500rpm, the material is sent out smoothly and the component is not changed.
Lobe pump can transfer high viscosity material, so it also called colloid pump.
Lobe pump can be made as rather high output pressure conveniently, suitable to long distance or high resistance dosing transfer.
Application
1). Food and beverage: dairy, chocolate, syrup, cream, cereal mash, beer and latex.
2). Fruit concentration: tomato paste, pudding, juice, jam and jelly.
3). Paste products: fats, grease and etc..
4). Cosmetic: face cosmetic, abluent, fixature, spice and so on.
5). Medicine: extract, emulsion and pill plasm.
6). Chemical industry: dyes, grease, dissolvant, resin and polymer.
Technical Parameter:
Model | L/100R | rpm | Flow rate | Power | Inlet | Connection |
BLS-3 | 3L | 200-500 | 300-800 | 0.55 | Φ25*1.5 | clamp |
BLS-6 | 6L | 200-500 | 650-1600 | 0.75 | Φ25*1.5 | |
BLS-8 | 8L | 200-500 | 850-2160 | 1.5 | Φ32*1.5 | |
BLS-12 | 12L | 200-500 | 1300-3200 | 2.2 | Φ38*1.5 | |
BLS-20 | 20L | 200-500 | 2100-5400 | 3 | Φ8*1.5 | |
BLS-30 | 30L | 200-400 | 3200-6400 | 4 | Φ2*1.5 | |
BLS-36 | 36L | 200-400 | 3800-7600 | 4 | Φ50.8*1.5 | |
BLS-52 | 52L | 200-400 | 5400-11000 | 5.5 | Φ63.5*1.5 | |
BLS-66 | 66L | 200-400 | 7100-14000 | 7.5 | Φ63.5*1.5 | |
BLS-78 | 78L | 200-400 | 9000-18000 | 7.5 | Φ76*2 | |
BLS-100 | 100L | 200-400 | 11000-22000 | 11 | Φ76*2 | |
BLS-135 | 125L | 200-400 | 15000-30000 | 15 | Φ89*2 | |
BLS-160 | 160L | 200-400 | 17000-34000 | 18.45 | Φ102*2 | |
BLS-200 | 200L | 200-400 | 21600-43000 | 22 | Φ102*2 |
Product Photos:

| Please contact our After-sales service department in time within 30days after you received the cargo. | |
| Tel: 86-577-86821328 Time: 9:00 a.m.- 6:00 p.m. (Beijing time) | |
| Process | Please provide the copy of Sales Contract and describe the problems appeared. |
| Problems confrimation: | |
| Slight problem: | Please send the proof to our After-Sales Department, we will reply within two days. |
| Serious problem: | |
| a | We will dispatch our Quality and Problems Appraisers to make a confirmation. |
| b | Have a negotiation of the compensation and sign agreements |
| c | Our After-Sales Department will perform the duties as the agreements |
