Home > Products > plastic pipe line > HDPE Pipe Plant-PE Pipe Machinery- Plastic Pipe Production Line
HDPE Pipe Plant-PE Pipe Machinery- Plastic Pipe Production Line
- 2 Set / Sets per Month
- Qingdao
- T/T L/C
- 40 days
You May Like
-
Pvc Pipe Extrusion Production Making Manufacturing Machine Pvc Pipe Extruder Machine With Price For Sale Made In China
-
PVC Garden Soft Pipe Production Machinery- PVC Fiber Enhancing Hose Extrusion Line-Plastic Soft Pipe Plant
-
Cable Protection Pipe Production Line-HDPE Cable Protection Pipe Machine- Communication Cable Protection Pipe Line
-
PPR Cold and Hot Water Pipe Making Machine Price, PPR Pipe Extrusion Machine PPR Multi-Layer Pipe Co-Extrusion Line
-
PP Hollow Grid Sheet Extrusion Line, Plastic Hollow Grid Plate Extruder Machine, Plastic Hollowness Grid Board Line
Product Details
| Brand Name | PERFECT | Place of Origin | China | |
| Model Number | HDPE Pipe Extrusion | Certification | CE ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas | Weight | 8T | |
| Dimension(L*W*H) | 22*2.8*2.5m | Voltage | 50-110V | |
| Application | Pipe | Condition | New | |
| Power(W) | based | Automatic Grade | Automatic | |
| Plastic Processed | PE | Screw Design | Single-screw |
Product Description
The Feature of HDPE Water /Gas Pipe Extrusion Line:
1.High speed single screw extruder, large output.
2. Quality 40Cr Molds, which assures stable extrusion.
3. It has advanced water circulation and high pressure cooling system, that ensure the stability of pipe size when high-speed operation.
4.Vaccum Calibration, accurately controlled water temperature and water level.
5. We can offer two tracks, three tracks, four tracks, five tracks and six tracks Haul-offmachine according to different diameter and wall thickness of the pipe.
The Working Process of HDPE Water /Gas Pipe Extrusion Line:
Raw Material---Mixing---Auto feeder and drier---Single screw extruder---Co-extruder---Mould Calibrator---Vacuum forming table---Water cooling tank---Haul-off machine---Cutting machine---Winding Machine.
Main Parameters of HDPE Water /Gas Pipe Extrusion Line:
Model | Diameter (mm) | Extruder | Max. Speed (m/min) | Output (Kg/h) | Power (Kw) | Dimension |
PE-63 | 20- 63 | SJ-65×33 | 35 | 120 | 65 | 30×2×3m |
PE-110 | 20- 110 | SJ-65×33 | 25 | 220 | 110 | 32×2×3m |
PE-160 | 63- 160 | SJ-75×33 | 20 | 300 | 150 | 32×2×3m |
PE -200 | 75- 200 | SJ-75×33 | 16 | 300 | 150 | 32×2×3m |
PE -250 | 75- 250 | SJ-90×33 | 4.5 | 400 | 200 | 40×2×3m |
PE -315 | 110- 315 | SJ-90×33 | 3.5 | 400 | 200 | 40×2×3m |
PE -400 | 160- 400 | SJ-120×30 | 2.5 | 550 | 280 | 42×3×3m |
PE -500 | 200- 500 | SJ-120×30 | 1.5 | 600 | 360 | 42×3×3m |
PE-630 | 315- 630 | SJ-120×33 | 1 | 800 | 450 | 50×3×4m |
PE-800 | 500- 800 | SJ-150×33 | 1 | 1000 | 750 | 60×5×4m |
PE-1000 | 500-1000 | SJ-150×33 | 1 | 1000 | 850 | 70×5×5m |
