Square and Rectangular Pipe for Solar Energy System
- Qingdao/Tianjin China
- T/T PayPal
You May Like
Product Details
| Thickness | 1.0, 40.0 | Section Shape | Square | |
| Outer Diameter | 15x15--800x800mm,20x30--600x800mm, 15*15---800*800mm,20*30----600*800mm | Place of Origin | Shandong, China | |
| Secondary Or Not | Non-secondary | Application | Structure Pipe | |
| Technique | ERW | Certification | CE | |
| Surface Treatment | Other, black,oiled,paint,galvanized,mirror,hairline | Special Pipe | Thick Wall Pipe | |
| Alloy Or Not | Non-alloy |
Product Description
Specifications
RHS SHS CHS STEEL TUBE1 OD:15*15-800*800mm,20*30--600*800mm
2 Thickness :1.0--40.0mm
3 MS,welded,seamless,GI,stainless,alloy
If you’re looking for high quality, competitive price Square&Rectangulare Hollow Section Steel Tube you’ve come to the right place.
Square and Rectangular Pipe for Solar Energy System
(1/2 inch to 32 inch)
Company Profile
COMPANY PROFILE
Jinan Xin Jiyuan Special Section Tube Co.,Ltd(Shandong,China), founded in 1997.We devote continuously to the research,development and usage of SQUARE & RECTANGULAR HOLLOW SECTION STEEL TUBES.
Main products are special shaped steel tube, cold..rolled precision tube, cold.rolled shaped tube. And our special shaped new materials enjoys advantage in high strength, super low temperature, impact..enduring, longevity, anti-erosion and easy-jointing.
There are three production lines,make full sizes of tubes: 15x15mm--800x800mm, 20x30mm--600x800mm,
over 2800 kinds of specifications.Materials are:seamless,stainless,galvanized,welded,carbon,low-alloy,alloy,
etc.
The products is very popular in USA Canada UK Australian Russia India Malaysia Europe and other countries and regions.
PRODUCTS
Products |
Square & Rectangular Hollow Section Steel Tube
|
Out Diameter | 15X15mm---800X800mm 20X30mm---600X800mm |
Thickness |
1.0mm---40.0 mm |
Material |
Carbon,Low-alloy,Alloy,Seamless,Welded, Stainless |
Technology |
ERW,Hot-Rolled,Cold-Formed,Annealed |
Standard |
GB/T ASTM JIS DIN EN AS |
Steel Grade |
Q235B, Q345A/B/C/D/E |
Gr.A Gr.B Gr.C Gr.D(HEAT TREATMENT) | |
SS330,SS400,STK490 C250,C350,C450 | |
S185, S235JR,S235J0, S355JR,S355J0,S355J2 | |
20#, 45# ,304,304L,316,316L,etc. | |
Surface | Black,Oiled,Paint,Hairline,Mirror,Galvanized,Anti-corrosive |
PRODUCT USE
Our products applies to the manufacture of cars, trucks, buses, special automobiles, agricultural
machines, high speed trains, aviation, shipbuilding, petroleum platform, petroleum land platform,
iron tower, bridges, large scale steel frame, port machine, textile machine, power plant, mining,
Technical requirements:
Chemical Composition:
Yield Strength Grade | Demotic Raw-material Grade |
235 | Q235B, Q235C, Q235D, Q235qC, Q235qD |
345 | Q345A, Q345B,Q345C,Q345D,Q345Qc, Q345Qd, StE355, B480GNQR |
Carbon Equivalent:
Ceq(%)=C+Mn/6+Si/24 +Ni/40+Cr/5+Mo/4+V/14
Ⅰgrade product Ceq(%)
Yield Strength Grade | 235 | 345 | 390 |
Ceq(%) | ≤0.36 | ≤0.43 | ≤0.45 |
Note: In order to improve the performance of steel,390 could add the microelement such as V, Nb, Ti, Mo and N etc. | |||
Mechanical Property:
Yield Strength Grade | W.T | Yield Strength | Tensile Strength (Mpa) | Elongation | (20°C) Impact Value J |
(mm) | (Mpa) | (%) | |||
235 | 4~12>12~22 | ≥235 | ≥375 | ≥23 | ≥27 |
345 | 4~12>12~22 | ≥345 | ≥470 | ≥21 | ≥27 |
390 | 4~12>12~22 | ≥390 | ≥490 | ≥19 | ≥27 |
