Full-automatic Round Bottle pet bottles sleeving labeling machine

automatic shrink sleeve label machine for bottle

Our shrink labeling machine is widely used for various bottles suitable for food, beverage, diary, chemical, health beauty products.

We have wide range of capacity from 100b/min-600b/min

                               6000b/h-36000b/h

Main machine: contact surface control

              applying Stainless steel

quick and easy changeover ,need replace the central mould

production run counter

surface of the label after shrinking smooth and no rumple and closely attach to the bottle body not falling off.

Features:

1. The machine is made of stainless steel and high quality Aluminum alloy, structure in reason, tighten, adjustment conveniently.
2. Not need ground feet bolts, move conveniently, flexible assort production field.
3. Shrink film volume label frame, according to different volume label paper pipe adjusted range 5"---10".
4. Transmission machine can be adjusted conveniently without tools, which makes it more suitable for bottle sizes.
5. Forced insertion design proves reasonable and convenient.
6. Volume label cut of measure system ensure little error.
7. Special designed knife plate is change free with the related specification.
8. Newel nip system, change and installation rapidly without tools.
9. Disport bottle screw, located strap, transport chain adopts synchronization adjust model, adjust facility.
10. Introduction Japanese servo motor and high-delicacy photo electricity, the length of cutting label is precision.

Technological parameters

The machine technical standards

Standard item         Standards and Tolerance

capacity                  ≥100-500bottles/min(as customer requirement)

label loss rate           ≤0.3%-0.7%

After cutting height error label      ≤±1.5mm.

Noise (in running)        <85dB(A)

the insulation resistance between the electrical components and the body ≥1M

Resistance values   ≤0.1

Label Appearance situation: cutting surface smooth, no glitches and other phenomena not significantly skewed. Complete label designation.

After-sales service:

1. We have professional service team, with commissioning and maintenance experience is more than 5-10 years

2. We honest commitment to customer service, to protect the interests of users with the greatest after-sales service (hotline 48 hours to provide technical support.)

3. We have offices in Guangzhou, providing in Guangdong and surrounding provinces service.

4 Three days complete the machine on-site installation and commissioning work

5. Responsibility for the whole year free warranty parts
