Hot Sale 3-5 gallons barreled water production Machine

FOB Price

USD $1,000 - $20,000 / Unit

1 Unit(Min.Order)

Supply Ability 30 Unit / Units per Month
Port shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	JZ
Model Number	QGF		Certification	ISO

Product Description

Description

5 gallon water filling machine-Characteristics

5 Gallon Water Filling Machine

1) Feature

Lonhon QGF series 20 Liter Water Bottle Machine is designed for producing 5 gallon barrel drinking water. There are 8 kinds of machines which can produce 60, 100, 150, 300, 450, 900, 1200 and 2000 5 gallon barrel drinking water per hour. Every machine is consisted of rinser, filler and capper. The rinser has several sprays which can be used as for both clean water rinsing and disinfectant rinsing. The disinfectant can be recycled. The machine also has automatic capping device, and cap rinsing device. The whole production line can automatic feeding barrel, rinsing, sterilizing, filling, capping, counting and output.

2) Technique Parameter

	QGF 60	QGF 100	QGF 150	QGF 300	QGF 450	QGF 600	QGF 900	QGF 1200	QGF 2000
Filling volume (L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Bottle specification (mm)	270*490	270*490	270*490	270*490	270*490	270*490	270*490	270*490	270*490
Capacity	60	100	150	300	450	600	900	1200	2000
Air pressure (MPa)	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5	0.5
Air consumption (L/min)	200	300	300	400	500	500	800	1200	1200
Power (kW)	1.4	2.12	3.77	6.5	7.5	7.5	10	14	15
Rated voltage (V)	380	380	380	380	380	380	380	380	380
Dimensions (LWH) (mm)	24708001580	34857001550	468514201700	513025002220	660035002170	660035002170	660050002170	280024002700	290035002700
Weight (kg)	800	800	1000	1750	2200	2500	2800	3100	4000
