Small Prefab Houses

Steel framing: 2~10mm , cold-formed steel& hot-rolled beam, strength: G250~350

Dimension:

10’: 3027x2435x2591/2791mm

20’: 6055x2435x2591/2791mm

30’: 9000x2435x2591/2791mm

40’: 12192x2435x2591/2791mm

Roof: 0.5mm color-bond steel sheet roof

Floor: 18mm plywood board& fiber-cement board+1.5~3.5mm vinyl sheet &15mm bamboo flooring

Window: UPVC double glass tilt& swing window with Alu. Roller shutter

External door: Steel security door

Internal door: UPVC internal door& Aluminum frame sandwich panel door

External wall panel: 50/60/75/100/150mm sandwich wall panel

Internal wall: 50/60/75mm sandwich wall panel

Ceiling: 50mm EPS& rock-wool sandwich ceiling panel

Sanitary: White ceramic

Kitchen: MDF cabinet surface with lacquered paint and bench top with quartz stone

Electrical fittings: Wiring, power point, switch, light, circuit-breaker etc

Gutter: PVC gutter with down pipe.

Package:

1. All the materials are well packed by the plywood or the steel skid before loading the container.
2. 20’ SOC container can load 4 units 20’ unit, 40’ HQ SOC can load 4 units 40’ unit, 4X30’units can loading into the 1x40’HQ.
3. All the materials are well fixed and tight to prevent the moving during the transport.
4. We will give the professional suggestion before you play the order to utilize the space of the container
