Water-cooled Diesel Engine CGZ12 CHANGGONG 3 cylinder diesel engine

CCHANGGONG  Water-cooled  CGZ12 Diesel Engine  description:

Application:

water-cooled  CGZ12 Diesel Engine  mainly apply to small tractors, farm vehicles, small generators, air compressors, inland shipping and power plant of agricultural processing (such as threshers, rice mills, milling machines, feed crusher, etc.).

Feature:

• new design make diesel engine more beautiful;
• low noise
• low vibration
• low consumtion

• TYPE	CG8(R176+)	R175A	R180	R180N	CGZ12(ZR12)	CG16(R16)
  (type)	singler-cylinder horizontal water-cooled foer-cycle
  (combustion model)	swirl-type	swirl-type	swirl-type	swirl-type	direct-injection	swirl-type
  (mm) (cylinder diameter)	80	75	80	80	92	100
  (mm) (piston stroke)	65	80	80	80	95	100
  (L) (displacement)	0.327	0.353	0.402	0.402	0.632	0.785
  (HP/r/min) (nominal speed/speed)	7.7/3000	6.6/2600	7.7/2600	7.7/2600	12/2400	16/2400
  (N.m) (maximum torque)
  (r/min) (The maximum torque speed)
  (g/kw.h) (Calibration to ignite fuel consumption)	≤294	≤280.2	≤278.8	≤278.8	≤266.6	≤245
  (r/min) (dling)	≤850	≤850	≤850	≤850
  (compression ratio)	22±1	22±1	22±1	22±1	21±1	18±1
  (staring mode)	(hand staring electricity staring)
  (Kg) (net weight)	45	68	72	72	95	102
  (mm) (overall dimensions)	486×255×352	589×341×463	625×341×463	625×341×463	670×378×560	730×390×570





•

  1PC/ EXPORT CARTON, WOODEN BOX, or as your demand

  JIANGSU CHANG GONG POWER MACHINERY CO., LTD is a subsidiary corporation of CHANG GONG INVESTMENT GROUP by producing and selling single cylinder diesel engine professionally. It established in 1998. Through the development in recent years, the company has already become the most competitive enterprise of agricultural machinery trade. At the beginning development, CHANGGONG establishes the aim of base for the mechanization of agriculture of China for a long time, the company insists all the time this aim unwaveringly. No matter production, marketing and service networking, all center on this aim firmly, and to realize mechanization of agriculture as our duty.
