SYG502 Popular Professional 5 Dots and 1 Cross Line Laser Marker

SYG502 Popular Professional 5 Dots and 1 Cross Line Laser Marker

Specifications

Lasers:5 dots, 1V-1H

Horizontal line accuracy: ≤ ± 3mm /10m

Vertical line accuracy: ≤ ± 3mm /10m

Up beam accuracy: ≤4mm /10m

Operation time: >Down beam accuracy: ≤6mm /10m

Left right and front 3 dots leveling accuracy: ≤4mm /10m

Superposition accuracy(Dots & lines): ≤ 5mm /10m

Self-leveling range: 4°±1°

Dot Working range: ≤30m

Line Working range: ≤10m; >25m with Laser detector

Diode power: 635nm±5nm, Class 2M

Operation time: >Working time: ≥7hs

Dimensions(LxWxH): 116x69x112mm

Self-Leveling with magnetic pendulum.

Features

Small size unit and can be hold in hand easily

High visibility laser line .full orientations,high stability,handeling

5beams & 1V,1H(cross over the ceiling) ,laser lines have a large fan angle (150°)

Laser lines & laser dots can be combined or independent for operation

Operation time: >Laser line or laser dots blink if the unit is out of the self-leveling range

Center locking system to lock the pendulum while in transportation to avoid the vibration(patent).

In /Outdoor function for option.(working with laser detector).

Tilting fuction(turn off the warning when the laser exceed the leveling range by the lock)

Compact size and handling housing with elastomeric rubber for easy carrying.
