53010557AA S822T Engine Timing Camshaft Sprocket for JEEP Wrangler 4.0L L6 242 CID
Negotiable
/ Piece
1 Piece(Min. Order)
- Qingdao
You May Like
-
C45 Steel MD021170 S407 Roller Crank Timing Sprocket Wheel With 8mm Pitch 34 Teeth
-
C45 Steel D9HZ6306A S401 Roller Crank Timing Sprocket Wheel With 9.525mm Pitch 22 Teeth
-
Gray Cast Iron HT250 Material 2463037 S380 Cam Roller Timing Sprocket Wheel With 9.525mm Pitch 50 Teeth
-
C45 Steel 14022646 S375 Crank Roller Timing Sprocket Wheel With 12.7mm Pitch 18 Teeth
-
C45 Steel 2205568 S339 Crank Timing Sprocket Wheel With 9.525mm Pitch 25 Teeth
-
C45 Steel 2532491 S367 Crank Timing Sprocket Wheel With 12.7mm Pitch 19 Teeth
Product Details
| Type | Transmission Gear | OE NO. | 53010557AA | |
| Car Make | JEEP 4.0 | Model Number | S822 |
Product Description
Specifications
1.Standard & Customized gear & sprocket2.High Quality
3.Made by ourselves instead of others
4.More than 10 years experience
S822T Engine Timing Camshaft Sprocket for JEEP 4.0L
Our Main Products (Since 2003):
1. Gear & Sprocket & Timing Kit: spur gear, bevel gear, helical gear, pinion,
roller chain sprocket, drive/ driven sprocket and so on.
2. Agricultural Gear & Sprocket
3. Industrial Gear & Sprocket
4. Motorcycle Gear & Sprocket
5. Timing Kit
4. Motorcycle Gear & Sprocket
5. Timing Kit
Japanese: Toyota, Nissan, Mazda, Mitsubishi, Honda, ISUZU etc.
American: Ford, Chevrolet, GMC, Dodge, Buick, Cadillac etc.
Russian: Lada etc.
6. Mechanical Transmission Parts
(wheel gear, sprocket, standard roller sprocket, non-standard sprocket, special non-standard parts,
American: Ford, Chevrolet, GMC, Dodge, Buick, Cadillac etc.
Russian: Lada etc.
6. Mechanical Transmission Parts
(wheel gear, sprocket, standard roller sprocket, non-standard sprocket, special non-standard parts,
spline, keyway, axle, flange, guide rail, tensioner, chain, spline shaft, steel bushing etc.)
Treatment process:
Casting / Forging
Paint / No Paint
Galvanized / White Zinc Plated
Quenching / Tempering
Black Finish / Bluing
Thermal Refining
CNC Line
Sand Blasting
Material:
| Material | Tooth Surface Hardness | Range of Application |
| 15, 20 Steel | carburizing and quenching 50~60 HRC | apply to Z≤25 high speed, overload, impact load sprocket |
| 35 Steel | normalizing 160~200 HBS | apply to Z>25 low speed, light load, smooth drive sprocket |
| 45, 50, ZG45 Steel | under the working conditions of low medium speed, light medium load, no violent shock, vibration and easy abrasion sprocket | |
| 15Cr, 20Cr | carburizing and quenching 50~60 HRC | apply to Z<25 high power drive sprocket, high speed and overloaded important sprocket |
| 35SiMn, 35CrMo, 40Cr | high speed, overload, shock, continuous work sprocket | |
| Q235, Q275 | 140 HBS | medium speed, transmission medium power sprocket, larger sprocket |
| Gray cast iron ( No less than HT200) | 260~280 HBS | smooth load, lower speed, more teeth driven sprocket |
| Grey cloth bakelite | transmitted power less than 6 kw, high speed, smooth transmission and low noise sprocket |
Package:
Plastic Bag + Paper Carton + Wooden Case
Advantages:
1. Alibaba's 6thyear member 2. Standard & non-standard & custom design 3. Since the 1990s, we began to export Europe, America, Germany and other countries and regions. 4. Win a good reputation at home and abroad 5. Widely used in hoisting machinery, motor repair machinery, machinery manufacturing, conveyor equipment etc. 6. Agricultural machinery sprockets: We are the complete sets of gear, chain wheel, shaft and other transmission parts fixed point production enterprise of Shanghai Lonking (zhongyuan II), YTO Group (Red East or Dongfang Hong) and other famous China companies. |
Certificate: TUV Rheinland
Our Factory and Workshop:
Trade Show:
Contact Us
- Henan Tianlong Machinery Manufacture Co., Ltd.
- Contact nameYameng Tsai Chat Now
- Phone0086-373-3350555
- AddressNO.101XIMA ROAD, FENGQUAN AREA , Xinxiang, Henan
