Factory Direct Sell First-class Quality Small Wood Chips Rotary Drum Dryer
- Qingdao Shanghai
- T/T Credit Card
You May Like
-
High Quality Biomass/coal/pellet Rotary Dryer Price
-
China Professional Wood Chip Dryer/Mesh Belt Drying Machine/Cassava Drying Machine
-
Factory Direct Sell Pellet Dryer /coal Rotary Dryer Price
-
Rotary Drum Dryer for Fertilizers /biomass Rotary Dryer Price
-
High Efficiency Drum Dryer Rotary Dryer/industrial Dryer Price
-
Factory Direct Sell Sawdust/wood Chips Dryer Machine
Product Details
| Condition | New | Type | Rotary Drying Equipment | |
| Place of Origin | Henan, China | Brand Name | Telon | |
| Model Number | TL-800*8000 | Voltage | 380V | |
| Power(W) | 4kw | Dimension(L*W*H) | 800*8000mm | |
| Weight | 3.5t | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Factory direct sell First-class quality Small wood chips rotary drum dryer
less consumption rotary drum dryer for coal Introduction:
slag drier is handling by bringing it into direct contact with a heated gas. The dryer is made up of a large, rotating cylindrical tube,The dryer slopes slightly so that the discharge end is lower than the material feed end in order to convey the material through the dryer under .
Advantage:
1.this machine has the automatic adjustment system,the dryer can rotate stable.
2.the structure of this rotary dryer is available for increasing the remain time of the raw material,thus increase the time of heat exchange, the usage of the power and also reduce the volume of land occupation.
3.the rotate speed can adjust by you need to control the drying time.
4.the operation of the dryer is automatic with less staff.
Rotary Drum Dryer Structure:
Rotary dryer machine is mainly composed of shell, back and forth supporting wheel, feeding and discharging unit and gear cap. The accessories which are not in the the scope of this machine include firebox, feeding and discharging equipment, dust catcher, etc.
Parameter
Type(mm) | Indiclination (%) | Rotation speed (r/min) | Input temperature (ºC) | Motor power (kw) | Output (t/h) | Weight (t) |
Φ600×6000 | 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
Φ800×8000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
Φ800×10000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
Φ1000×10000 | 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
Φ1200×10000 | 3-5 | 3-8 | ≤700 | 7.5 | 1.8-5 | 14.5 |
Φ1200×12000 | 3-5 | 3-8 | ≤700 | 11 | 2-6 | 14.8 |
Φ1500×12000 | 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
Φ1800×12000 | 3-5 | 2-6 | ≤800 | 18 | 5-12 | 25 |
Φ2200×12000 | 3-5 | 1.5-6 | ≤800 | 18.5 | 6-15 | 33 |
Φ2200×18000 | 3-5 | 1.5-6 | ≤800 | 22 | 10-18 | 53.8 |
