HOT sale M36X3 heli/coil type screw thread insert
USD $0.04 - $0.8
/ Piece
200 Pieces(Min.Order)
- 3000000 Piece / Pieces per Month
- Tianjing Qingdao
- T/T L/C Other
- 7 days
You May Like
Product Details
| Brand Name | bashan | Place of Origin | China | |
| Model Number | M36X3 |
Product Description
| Material: | Stainless Steel | Coating: | Plates The Titanium/cadmium/galvanization |
|---|---|---|---|
| Color: | Red,green, Yellow,original | Model Number: | M36X3 |
| Used: | Building, Automobile Industry, Furniture, Sanitary, Electronics, Traffic. | Thread: | Coarse, Fine |
| Type: | Free Running Insert | Standard: | Metric |
| Place Of Origin: | Henan, China (Mainland) | Brand Name: | Bashan |
Description
HOT sale M36*3 strip feed reel thread insert
1.Size: M36*3
2.Place of Origin:Henan, China (Mainland)
3.Brand Name:bashan
4. Certification: Passed ISO9001:2008 quality certificate
Passed ISO/TS16949:2009 certificate
Passed GJB9001A-2001 military quality certificate.
5. Length: 0.5D=18mm, 0.75D=27mm, 1D=36mm, 1.5D=54mm
6. Standard: MERTRIC/UNC/UNF/
Description
HOT sale M36*3 strip feed reel thread insert
| Product Name | HOT sale M36*3 strip feed reel thread insert |
| Material | stainless steel 304 |
| Length | 0.75D=12mm, 1D=16mm, 1.5D=24mm,2D=32mm |
| Color | original/red/black/purple/gloden |
| Standard | MERTRIC/UNC/UNF/ |
| Circle | 4.4K, 7.1K, 9.9K, 15.4K |
| Coating | plates the titanium/cadmium/galvanization |
| Weight/1000pcs | 29.72KG, 44.59KG, 59.45KG, 89.17KG |
| Type | free-running insert,screw-lock insert |
| Outside diameter | 42.1—42.6 |
| Drill diameter | 36.8mm |
| install tool size | Size:M36*3 |
| Break tool size | Size:M36*3 |
| Unload tool size | Size:M36*3 |
| Used | building industry machinery, construcuion |
Specification1.Free run type: M2X0.4~M60X4mm.
2.Screw-locking type: M2X0.4~M60X4mm.
2.Screw-locking type: M2X0.4~M60X4mm.
Specification d×p | Nominal length L×d | W | Dz | d0 | |||
| d | p | ×d | L1 | min | max | ||
36 | 0.5d | 18.0 | 4.4 | 42.10 | 42.60 | 36.8 | |
| 0.75d | 27.00 | 7.2 | |||||
| 1d | 36.0 | 9.9 | |||||
| 1.5d | 54.0 | 15.3 | |||||
| 2d | 72.0 | 20.5 | |||||
| Material | Grade | Temperature Under Used | Tensile Strength Under Room Temperature | Surface |
Stainless Steel | 0Cr18Ni9 | 425°C short time 315°C long time | No coated Coat lubricant on the surface Coat Cr Coat Ag | |
| 1Cr18Ni9Ti | ||||
| 1Cr18Ni9 | ||||
Nimonic90 | short time 550°C long time | >1400Mpa | Coat Ag | |
Products show
HOT sale M36X3 heli/coil type screw thread insert
Features:
1.Abrasion resistant
2.Corrosion resistant
3.Heat-stable
4.Saving material
5.Increasing the bearing capacity and fatigue resistant of the insert connecting part
1.Abrasion resistant
2.Corrosion resistant
3.Heat-stable
4.Saving material
5.Increasing the bearing capacity and fatigue resistant of the insert connecting part
Installation tool
Installation Steps
1.drilling 2.tapping 3.put thread in wrench 4.installing
5.breaking 6.finished 7.putting bolt in
Packaging & Delivery
Packaging Details:
inner: plastic bag
outer: paper box or wooden case,depending on the weight
Delivery Detail:
according to the customer's requirement
Our Certifications
1)Passed ISO9001:2008 quality certificate
2)Passed ISO/TS16949:2009 certificate
3)Passed GJB9001A-2001 military quality certificate.
4)Drafted GJB119.1A-119.4A-2001, GJB107-5110-2002, GB/T5330-2003,HB1862-93
Our company
Xinxiang Bashan Aero Material Co., Ltd., affiliated to China Aviation Industry Corporation (AVIC), is a specialized manufacturer with a history more than 62 years. Our main products are metal wire, wire cloth, test sieve, filter element, filter, steel thread insert, steel reed, metal sintered fiber, edm brass wire, screener and other related products. Our company has independent import and export rights. With plant area covering about 50,000 square meters, we employ more than 200 managerial and technical personnels and 800 skilled workers. Since 1986, we have been exporting wire mesh for buyers in USA. Meanwhile, we carry out a strict quality management system in accordance with ISO9001,TS16949,ISO 14001. Bashan has a wide range of products including all kinds of metal wire, wire cloth, filter element, thread insert, screener, etc. There are over hundreds specifications of wire mesh we can supply and we can offer almost everything which is related with wire and mesh
