5 ton solid waste equipment garbage loader with 3.5m3 bucket and 220HP diesel engine
- Qingdao Port China
- T/T L/C D/P D/A
You May Like
-
5 ton wheel loader with cheap price better than LW500FN
-
AS936 High-quality 4-wheel-driving compact 3 ton China used wheel loader
-
AS936 High-quality 4-wheel-driving compact 3 ton China wheel loader 97KW
-
AS916 wheel loader with 0.8 m3 bucket and XINCHAI 45kw diesel engine
-
AS966H Construction machines 966H heavy wheel loader black and white
-
AS966 Construction machines 966H heavy wheel loader black and white
Product Details
| Condition | New | Brand Name | ANSION | |
| Model Number | AS956 | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 7930 x 3050 x 3400 mm | Rated Load | 5000 kg | |
| Certification | ISO9001 | Warranty | 12 months | |
| After-sales Service Provided | No overseas service provided |
Product Description
1 | rated load | 5000kg |
2 | overall weight | 16500kg |
3 | rated bucket capacity | 3-4.5 m3 large bucket |
4 | maximum tractive force | 150KN |
5 | maximum breakout force | ≥155KN |
6 | maximum grade ability | 30o |
7 | maximum dump height | 3090mm |
8 | maximum dump reach | 1250mm |
9 | overall dimension (L×W×H) | 7920×3050×3400mm |
10 | minimum turning radius | 6640mm |
11 | model | Cummins 6CTA8.3-C215 / WEICHAI / SHANGCHAI |
12 | type | Four stroke water cooling injection pressure boost |
13 | No. of cylinder-bore/stroke | 6-114×135mm |
14 | rated power | 160kw--2200r/min |
15 | maximum torque | 980N.m/1500rpm |
16 | min fuel-consume ratio | ≤215g/kw.h |
17 | torque converter | planetary |
18 | Transmission model | ZL50 |
19 | gear shift | 2forward shift 1reverse shift |
20 | maximum speed | 30km/h |
21 | main reducing spiral
| bevel gear grade 1reduction |
22 | decelerating mode | planetary reduction,grade 1 |
23 | wheel base (mm) | 3200mm |
24 | wheel tread | 2250mm |
25 | minimum ground clearance | 480mm |
26 | system working pressure | 18MPa |
27 | boom lifting time | 5.7s |
28 | total time | 9.5±0.5s |
29 | fuel tank capacity | 270L |
30 | function of leveling automatically | yes |
31 | service brake | air over hydraulic disc brake on 4 wheels |
32 | parking brake | manual parking brake |
33 | type specification | 23.5-25 |
34 | front tyre pressure | 0.4Mpa |
35 | rear tyre pressure | 0.35Mpa |
QINGZHOU ANSION MACHINERY CO.,LTD was founded in 1999 and located at Caterpillar (Qingzhou) Industrial Zone, Qingzhou City, China. ANSION is a private-owned factory & exporting combined company, which specializes in the construction machinery , including wheel loaders, rock forklift loaders, backhoe loaders, forklift trucks, excavators, bulldozers, truck cranes, trench diggers and their spare parts. ANSION has become one of the famous Chinese construction machinery brands and focus on new requirements of different customers from all over the world.
