Home > Products > SKS & Backhoe Tyres > Backhoe Tire 19.5l-24
Backhoe Tire 19.5l-24
US$ 200 - 250
/ Piece
50 Pieces(Min. Order)
- Qingdao
- T/T
You May Like
Product Details
| Type | Tires | Use | Tractors | |
| Place of Origin | Shanghai, China | Brand Name | TNR | |
| Model Number | 19.5L-24 |
Product Description
Specifications
backhoe tire 19.5l-241. Agricultural Tire 19.5L-24 AR-4B
2. Ply Rating: 10PR/12PR
3. Bar Height: 30mm
backhoe tire 19.5l-24
Pattern Description:
1.Application to agricultural implement vehicles;
2.Application to be used on soft road, muddy road and desert;
3.Good traction performance;
backhoe tire 19.5l-24
Specification:
| Tire Size | PR | Type | Bar Height | Standard Rim | Available Rim | Inflated Dimensions | Max Load kg | Pressure Kpa | |||||
| TT | TL | mm | Inch | Section Width | Overall Diameter | ||||||||
| mm | Inch | mm | Inch | ||||||||||
| 7.50-16 | 6 | TT | 18 | 0.71 | 5.50F | -- | 205 | 8.07 | 765 | 30.12 | 650 | 210 | |
| 12.9-18 | 10 | TT | 22 | 0.87 | 9.00V | -- | 327 | 12.87 | 1090 | 42.91 | 1800 | 350 | |
| 16.9-24 | 8 | TL | 26 | 1.02 | W15L | -- | 430 | 16.93 | 1309 | 51.54 | 2650 | 190 | |
| 10 | 2900 | 220 | |||||||||||
| 17.5L-24 | 10 | TL | 26 | 1.02 | W15L | -- | 445 | 17.52 | 1241 | 48.86 | 2800 | 220 | |
| 12 | 3075 | 260 | |||||||||||
| 19.5L-24 | 10 | TL | 30 | 1.18 | DW16A | -- | 495 | 19.49 | 1314 | 51.73 | 3000 | 190 | |
| 12 | 3450 | 230 | |||||||||||
| 21L-24 | 10 | TL | 30 | 1.18 | DW18A | -- | 533 | 20.98 | 1378 | 54.25 | 3350 | 180 | |
| 12 | 3875 | 220 | |||||||||||
Tire Terminology
• Section height is the design height of a tire section measured from the base of the tire bead to the top of the tread.
• Section width is the width of a new tire, including 24-hour inflation growth and normal sidewalls, but not including protective side ribs, bars, or decorations.
• Aspect ratio is the section height divided by section width, and is measured as a percentage.
• Static loaded radius (SLR) is the dimension measured from the axle centerline to the ground when the tire is under load. SLR is usually specified at the tire's maximum load and inflation for that particular tire.
• Overall diameter is twice the section height of a new tire, including 24-hour inflation growth, plus the nominal rim diameter.
Agricultural equivalent sizes
| PART NUMBER | DUAL WHEEL SIZE | TO TAKE TYRE SIZE | |
| D1608 | 8 x 16 | 10.00 - 16 | 240/70 - 16 |
| 11.00 - 16 | 250/80 - 16 | ||
| D1611 | 11 x 16 | 13.0/75 - 16 | 320/65 -16 |
| D1809** | 9 x 18 | 10.5/80 - 18 | 275/80 - 18 |
| 12.5/80 - 18 | 335/80 - 18 | ||
| D1813** | 13 x 18 | 15.0/70 - 18 | 405/70 - 18 |
| D2009** | 9 x 20 | 10.5 - 20 | 275/80 - 20 |
| D2011** | 11 x 20 | 12.4 - 20 | 360/70 - 20 |
| 12.5/80 - 20 | 375/75 - 20 | ||
| D2013** | 13 x 20 | 14.9 - 20 | 380/70 - 20 |
| 16.0/70 - 20 | 400/70 - 20 | ||
| 420/75 - 20 | |||
| D2407 | 7 x 24 | 8.3 - 24 | |
| D2408 | 8 x 24 | 9.5 - 24 | |
| D2410 | 10 x 24 | 11.2 - 24 | 320/70 - 24 |
| 12.4 - 24 | |||
| D2412 | 12 x 24 | 13.6 - 24 | 340/85 - 24 |
| 14.9 - 24 | 380/85 - 24 | ||
| 420/65 - 24 | |||
| 420/70 - 24 | |||
| D2415-8 | 15 x 24 | 16.9 - 24 | 420/85 - 24 |
| D2415** | 17.5 - 24 | 460/70 - 24 | |
| 18.4 - 24 | 480/70 - 24 | ||
| D2416** | 16 x 24 | 19.5 - 24 | 540/65 - 24 |
| D2612 | 12 x 26 | 13.6 - 26 | |
| D2614 | 14 x 26 | 16.9 - 26 | |
| D2616** | 16 x 26 | 18.4 - 26 | 480/70 - 26 |
| 520/70 - 26 | |||
| 540/65 - 26 | |||
| D2620 | 20 x 26 | 23.1 - 26 | 620/70 - 26 |
| 620/75 - 26 | |||
| 650/70 - 26 | |||
| D2625 | 25 x 26 | 28.1 - 26 | 750/65 - 26 |
| D2810 | 10 x 28 | 11.2 - 28 | 280/85 - 28 |
| 320/70 - 28 | |||
| D2811 | 11 x 28 | 12.4 - 28 | 320/85 - 28 |
| 360/70 - 28 | |||
| D2812 | 12 x 28 | 13.6 - 28 | 380/70 - 28 |
| 340/85 - 28 | |||
| D2813 | 13 x 28 | 14.9 - 28 | 380/85 - 28 |
| D2813-10 | 420/65 - 28 | ||
| 420/70 - 28 | |||
| D2815-8 | 15 x 28 | 16.9 - 28 | |
| D2815 | 480/65 - 28 | ||
| 480/70 - 28 | |||
| D2816 | 16 x 28 | 18.4 - 28 | 540/65 - 28 |
| D2818 | 18 x 28 | 600/65 - 28 | |
| D2820 | 20 x 28 | 620/70 - 28 | |
| D3012 | 12 x 30 | 14.9 - 30 | 380/85 - 30 |
| 420/70 - 30 | |||
| D3015-8 | 15 x 30 | 16.9 - 30 | 420/85 - 30 |
| D3015 | 18.4 - 30 | 480/70 - 30 | |
| D3015-12 | 520/70 - 30 | ||
| D3016 | 16 x 30 | 18.4 - 30 | 540/65 - 30 |
| D3020 | 20 x 30 | 23.1 - 30 | 600/70 - 30 |
| D3020-14 | 620/75 - 30 | ||
| 650/70 - 30 | |||
| D3023 | 23 x 30 | 710/55 -30 | |
| D3210 | 10 x 32 | 11.2 - 32 | 270/75 - 32 |
| 320/85 - 32 | |||
| 12.4 - 32 | 300/95 - 32 | ||
| 320/90 - 32 | |||
| D3220 | 20 x 32 | 600/65 - 32 | |
| D3221 | 21 x 32 | 24.5 - 32 | |
| 650/70 - 32 | |||
| 680/70 - 32 | |||
| 680/75 - 32 | |||
| D3227 | 27 x 32 | 30.5 - 32 | |
| D3227-14 | 800/60 - 32 | ||
| 800/65 - 32 | |||
| D3410 | 10 x 34 | 290/95 - 34 | |
| 320/85 - 34 | |||
| D3413 | 13 x 34 | 380/85 - 34 | |
| D3415-8 | 15 x 34 | 16.9 - 34 | 420/85 - 34 |
| D3415 | 18.4 - 34 | 460/85 - 34 | |
| 480/70 - 34 | |||
| D3423 | 23 x 34 | 710/75 - 34 | |
| D3610 | 10 x 36 | 11.2 - 36 | 270/95 - 36 |
| D3611 | 11 x 36 | 12.4 - 36 | 320/85 - 36 |
| 13.6 - 36 | 340/85 - 36 | ||
| D3810 | 10 x 38 | 11.2 - 36 | 270/95 - 38 |
| D3812 | 12 x 38 | 13.6 - 38 | 340/85 - 38 |
| 14.9 - 38 | |||
| D3815-8 | 15 x 38 | 16.9 - 38 | 420/85 - 38 |
| D3815 | 18.4 - 38 | 460/85 - 38 | |
| D3815-12 | 480/70 - 38 | ||
| 520/70 - 38 | |||
| D3816 | 16 x 38 | 520/85 - 38 | |
| D3818 | 18 x 38 | 20.8 - 38 | 540/65 - 38 |
| D3818-14 | 580/70 - 38 | ||
| D3820 | 20 x 38 | 600/65 - 38 | |
| 620/70 - 38 | |||
| 650/65 - 38 | |||
| D3825 | 25 x 38 | 710/60 - 38 | |
| D4008 | 8 x 40 | 9.5 - 40 | 230/95 - 40 |
| D4216 | 16 x 42 | 18.4 - 42 | 480/80 - 42 |
| D4218 | 18 x 42 | 20.8 - 42 | 520/85 - 42 |
| D4218-14 | 580/70 - 42 | ||
| D4220 | 20 x 42 | 620/70 - 42 | |
| 650/65 - 42 | |||
| D4223 | 23 x 42 | 710/70 - 42 | |
| D4227 | 27 x 42 | 950/50 - 42 | |
| D4408 | 8 x 44 | 9.5 - 44 | 230/95 - 44 |
| D4410 | 10 x 44 | 11.2 - 44 | 270/95 - 44 |
| D4610 | 10 x 46 | 11.2 - 46 | 270/95 -46 |
| 12.4 - 46 | 300/95 - 46 | ||
| D4612 | 12 x 46 | 340/85 - 46 | |
| D4613 | 13 x 46 | 14.9 - 46 | 420/80 - 46 |
| D4616 | 16 x 46 | 520/85 - 46 | |
| D4620 | 20 x 46 | 620/70 - 46 | |
| D4808 | 8 x 48 | 9.5 - 48 | 230/95 - 48 |
| D4810 | 10 x 48 | 11.2 - 48 | 270/95 - 48 |
| D4812 | 12 x 48 | 13.6 - 48 | 340/85 - 48 |
| D5010 | 10 x 50 | 320/90 - 50 | |
| D5210 | 10 x 52 | 12.4 - 52 | 300/95 - 52 |
| D5410 | 10 x 54 | 11.2 - 54 | 270/95 - 54 |
