LQA Type Cardan Shaft

0.03 without length compensation, tubular design

9.01 with length compensation, short design

9.03 with length compensation, short design

9.04 without length compensation, double flange

 SWP subdivision type bearing the cross shaft universal coupling product introduction: To facilitate replacement bearing, SWP cross axle type universal shaft coupling bearing design is split, shaft bolt, is suitable for the rolling machinery, lifting transportation machinery and other heavy machinery, connecting two different axis transmission shafting, turning diameter from 160 ~ 640 mm; 16 ~ 1250 kn m., nominal torque axis Angle A ~ F type is not more than 10 ° , G type is not more than 5 ° .

687.15-65 Series Cardan shaft Data sheets

  Universal Joints / Drive Shaft / Cardan Shaft

Universal Joints / Drive Shaft / Cardan Shaft   advantage :

1.Excellent performance, long using life and competitive price.

2.Heat resistant&Distortion resistant
3.High intensity and rigidity.
4.Meet Iso9001: 2008 quality system
5.Your sample request are welcomed
6.With own R&D dept., OEM orders are available

Quality Control:
1.Chemical Composition confirm after Ingot
2.Hardness after Heat Treatment
3.Final Dimension Check

Quality Assurance Document:
1.Item Testing Plan will be submit to customer in 1 day after contract signed.
2.All the Q.A Document as per Client Requirement will be submitted before final product shipped out.

Packing and shipping:
1 Prevent from damage.
2. As customers' requirements, in perfect condition.
3. Delivery : As per contract delivery on time
4. Shipping : As per client request. We can accept CIF, Door to Door etc. or client authorized agent we supply all the necessary assistant

4.Drawings

02_ Universal Joints / Drive Shaft / Cardan Shaft

Universal joint cardan shaft for nuclear power station  Advantages / Features:

1. Materials:

Our company has purchased steel from several large steel groups , such as Hangzhou Steel Mill, Shanghai Bashan Steel Mill, Beijing Shrugging Steel Mill whose steel have good mechanical properties and stability of chemical component. it keep the shaft  to be of high quality.

2. Manufacture Procession

First, we have our own High-precision Digital Machining center for mould making in special Mould Workshop, excellent mould make product beautiful appearance and its size accurately.

The second, we adopt blasting procession, removing Oxidation surface, make the surface to be bright and clean and uniform and beautiful.

The third, in heat treatment: We use the Controlled-atmosphere Automatic heat treatment Furnace, we also have four mesh belt convey furnaces, Can deal with the products in different sizes keeping the non-oxidation surface

3. Quality Control:

The quality control is strictly performed from buying raw materials in warehouse to different machining procession and to final packing. 100% inspection during production .

CE
