Air Turnover Cutting Machine, AAC Block Machine, Concrete Block Machine,Autoclaved Block Plant

Auitable for long-distance delivery

I. Overview
     Based on the technology of Kehai company , our  Air Turnover Cutter is a simple, practical and highperformance cutting set developed under domestic physical circumstances.

II. Working Mode
     (1) Car Travel: turn over the prestreamed body with mould for 90°, then put the body on the cutting car, the stripping machine strips the die grid. After horizontal cutting by the horizontal cutting car, the transverse cutting car makes vertical cutting from above to below. And after vertical cutting, the transverse cutting car resets and lifts up the body, and the horizontal cutting car resets.
     (2) Body Travel: turn over the prestreamed body with mould for 90°, then put the body on the cutting car or the roller track, the stripping machine strips the die grid. The body passes through the cutting car or the roller track to make horizontal cutting and goes ahead to the pointed cutting position to make transverse cutting, and then goes on till the traveller lifts the body.

III. Main Characteristics
     1. This cutter has simple and compact structure, convenient for maintaination.
     2. It has high working efficiency, it can turn over blocks meanwhile cutting blocks.
     3. Balanced and reliable turnover.
     4. High cutting accuracy of blocks.
     5. Two models of transect drive: mechanical drive and hydraulic drive.
     6. It can do notch milling meanwhile cutting blocks, suitable for panel processing

............................................................................................................................................................

AAC Introduction

Basic concept

AAC is a siliceous material (sand, fly ash and silicon tailings such as waste porcelain clay, stone processing waste materials, blast furnace slag, etc.) and calcareous materials (lime, cement) as the main raw material, mixing fat gas agent (aluminum powder), by ingredients, mixing, casting, pre-raising, cutting, autoclave, curing process made of light porous silicate products, because by the hair contains a lot of gas even after the small pores, hence the name of aerated concrete.

The Performance Advantage

Lightweight: Porosity achieve 70% to 85%, volume density is generally 500 ~ 900kg/m3, as 1/5 of general concrete the 1/4of clay, the 1/3 of hollow brick, and similar with wood can float in water. It can reduce building weight, reduction in the cost of integrated building.

Fireproof: Most of the major raw materials is inorganic materials, so it has good fire resistance, and do not emit harmful gases when meet fire. Fire 650 degrees, as a refractory material, the thick up of 90mm walls can reach to 245 minutes fire resistance, 300mm thick up wall can reach to 520 minutes fire resistance.

Sound insulation: Due to a unique porous structure, so it has a sound absorption capacity. The sound absorption capacity can reach of 10mm thick wall up to 41 db.

Insulation: As the material inside has a large numbers of the pores and porous, which has a good thermal insulation properties. The Thermal conductivity is 0.11-0.16W/MK, as 1/4-1/5 of brick. Typically, the insulation effect of 20cm thick aerated concrete wall is equivalent to 49cm thick solid brick walls ordinary.

Permeability: Result of material by the composition of many independent small pores, the moisture absorption is slow, in the volume of absorbent is 5 times of clay saturation do. When used in the bathroom, the wall can be treated to interface directly paste tiles.

Anti-seismic: The same building structure, improve the two seismic than the brick level.

Pro-environment: Manufacturing, transportation, all use the process of pollution, to protect arable land, saving energy, is one kind of a green building material.

Durability: material strength is stability, in the specimens tested after one year of atmospheric exposure; the intensity increased by 25%, and remained stable after ten years.

Shortcut: it has good machinability, can be sawed, planed, drilled, nailed, and available appropriate as bonding of adhesive material, so create favorable conditions for building construction.

Cost-saving: An integrated lower cost than using more than 5% of solid clay bricks, and can increase the usable area, greatly enhance the utilization of floor space.
