Home > Products > Conveyor&Elevator > Bucket Elevator
Bucket Elevator
- Shanghai
You May Like
Product Details
| Condition | New | Type | Bucket Conveyor | |
| Material | Stainless Steel | Material Feature | Heat Resistant | |
| Structure | Conveyor System | Place of Origin | Jiangsu, China | |
| Brand Name | CWE | Model Number | BE | |
| Voltage | 220V 50hz | Power(W) | 3-75Kw | |
| Certification | SGS, SGS | After-sales Service Provided | Overseas service center available |
Product Description
AWE Bucket Elevators are used to elevate bulk materials vertically. A Bucket Elevator consists of a series of buckets attached to a belt or chain with pulleys or sprockets located at the top and bottom of the unit.
AWE bucket elevators are designed to service industries including chemical, minerals processing, grain, wood products and wastewater treatment. Bucket Elevators can be designed to suit the individual needs of your operation, taking into account variables such as bulk material characteristics, capacity and overall height.
| Model | BE160 | BE250 | BE315 | BE400 |
| Bucket | SMD | SMD | SMD | SMD |
| Capacity(m³/h) | 5 10 15 | 10 25 35 | 15 25 40 | 20 40 65 |
| Bucket Width(mm) | 160 | 250 | 315 | 400 |
| Bucket Capacity (L) | 0.5/4.2/1.9 | 1.3/3.0/4.6 | 2/3.8/5.8 | 3.1/5.9/9.4 |
| Bucket Pitch( mm) | 280/350 | 360/450 | 400/500 | 480/560 |
| Belt Width (mm) | 200 | 300 | 400 | 500 |
| Speed(m/s) | 1.4 | 1.6 | 1.6 | 1.8 |
| Max.Size(mm) | 25 | 35 | 45 |
55 |
Factory in Australia
Factory in China
Contact Person | Journey |
Skype | journey201314 |
If you want to have more information about our Buclet Elevator , please contact me.
